Load

8
Pulse/frequency/switch output
Pulse output
Failure mode
Frequency output
Failure mode
Switch output
Failure mode
Local display
Plain text display With information on cause and remedial measures
Backlight Additionally for device version with SD03 local display: red lighting indicates a device
error.
Status signal as per NAMUR recommendation NE 107
Operating tool
• Via digital communication: HART protocol
• Via service interface
Plain text display
With information on cause and remedial measures
Additional information on remote operation (® ä 33)
Load for current output: 0 to 500 W, depending on the external supply voltage of the power supply unit
Calculation of the maximum load
Depending on the supply voltage of the power supply unit (U
must be observed to ensure adequate terminal voltage at the device. In doing so, observe the minimum terminal
voltage (® ä 11)
£ (U
• For U = 18 to 18.9 V: R
S B
• For U = 18.9 to 24.5 V: R
S B
£ 500 W
• For U = 24.5 to 30 V: R
S B
Choose from:
• Actual value
• No pulses
Choose from:
• Actual value
• Defined value:0 to 1 250 Hz
• 0 Hz
Choose from:
• Current status
• Open
• Closed
S
- 18 V) : 0.0036 A
S
£ (U - 13.5 V) : 0.022 A
S
Proline Promag P 200
), the maximum load (R ) including line resistance
B
