Weight - Endress+Hauser Proline Promag P 200 Technical Information

Proline Promag P 200

Weight

Endress+Hauser
Dimensions in US units
DN A
[in] [in]
½ 0.63
1 1.02
1 ¼ 1.38
1 ½ 1.61
2 2.05
2 ½ 2.68
3 3.15
4 4.09
5 5.12
6 6.22
8 8.11
Compact version
Weight data:
• Including the transmitter (1.9 kg (4.2 lbs))
• Weight specifications apply to standard pressure ratings and without packaging material.
Weight in SI units
Nominal diameter
[mm] [in] Pressure rating
15 ½
25 1
32 1 ¼
40 1 ½
50 2
65 2 ½
80 3
100 4
125 5
150 6
200 8
1) For flanges to AS, only DN 25 and 50 are available.
Weight in US units
Nominal diameter
[mm]
15
25
32
40
50
B C
[in] [in]
1.69 2.42
2.44 3.05
3.15 3.44
3.23 3.98
3.98 4.55
4.76 5.18
5.16 6.08
6.14 7.34
7.36 8.13
8.54 10.1
10.5 11.3
1)
EN (DIN), AS
[kg] Pressure rating
PN 40 5.0 Class 150
PN 40 5.8 Class 150
PN 40 6.5 Class 150
PN 40 7.9 Class 150
PN 40 9.1 Class 150
PN 16 10.5 Class 150
PN 16 12.5 Class 150
PN 16 14.5 Class 150
PN 16 20.0 Class 150
PN 16 24.0 Class 150
PN 10 43.5 Class 150
[in] Pressure rating
½ Class 150
1 Class 150
1 ¼ Class 150
1 ½ Class 150
2 Class 150
D E
[in] [in]
2.87 0.26
3.44 0.26
3.72 0.26
4.06 0.26
4.25 0.26
4.65 0.26
5.31 0.26
6.02 0.26
6.30 0.26
7.24 0.26
8.07 0.26
ASME JIS
[kg] Pressure rating
5.0 10K
5.8 10K
– 10K
7.9 10K
9.1 10K
– 10K
12.5 10K
14.5 10K
– 10K
24.0 10K
43.5 10K
ASME
[lbs]
11.0
12.8
–
17.4
20.1
t
[in]
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
[kg]
5.0
5.8
5.8
6.8
7.8
9.6
11.0
13.2
19.5
23.0
40.4
