Measuring system

Measured variable

Measuring range

Endress+Hauser
The device consists of a transmitter and a sensor.
One device version is available: compact version, transmitter and sensor form a mechanical unit.
Transmitter
Promag 200
Sensor
Promag P

Input

Direct measured variables
Volume flow (proportional to induced voltage)
Calculated measured variables
Mass flow
Typically v = 0.01 to 10 m/s (0.03 to 33 ft/s) with the specified accuracy
Flow characteristic values in SI units
Nominal Recommended
diameter
min./max. full scale value
(v ~ 0.310 m/s/
[mm] [in] [dm
15 ½ 4 to 100
25 1 9 to 300
32 – 15 to 500
40 1 ½ 25 to 700
50 2 35 to 1 100
65 – 60 to 2 000
80 3 90 to 3 000
100 4 145 to 4 700
125 – 220 to 7 500
Materials:
Aluminum coating AlSi10Mg
Configuration:
• External operation via four-line, illuminated local display with touch control
and guided menus ("Make-it-run" wizards) for applications
• Via operating tools (e.g. FieldCare)
A0013471
Nominal diameter range: DN 15 to 200 (½ to 8")
Materials:
• Sensor housing: aluminum coated AlSi10Mg
• Measuring tubes: stainless steel 1.4301/304, 1.4306/304L
• Liner: PFA, PTFE
• Process connections: 1.0425/316L, 1.4571/316L, A105, C22, F316L, FE
410W B, HII, S235JRG2
• Electrodes: 1.4435/316L, Alloy C-22, tantalum, platinum
• Seals: as per DIN EN 1514-1
A0017703
• Ground disks: 1.4435/316L, Alloy C-22, tantalum
flow
Full scale value current
output
(v ~ 2.5 m/s)
3 3
/min] [dm
125
200
300
500
750
1 200
1 850
Factory settings
Pulse value
(~ 2 pulse/s)
3
/min] [dm ]
25 0.2
75 0.5
1
1.5
2.5
5
5
10
15
Low flow cut off
(v ~ 0.04 m/s)
3
[dm /min]
0.5
1
2
3
5
8
12
20
30
5
