Chattanooga Revolution Wireless Service Manual page 39

ERROR CODES
Code Description / Comment
0x4007 C_ErrorCpxRF01BadFwInfoChunk. RF reset error
0x271F ERROR_PROGMGR_WRONGOPMODE
0x00CF This might be an out of range side-effect
0x4104 RFNode not properly reset. Check (triple) the RF reset from remote.
0x1140 C_ErrorDevlibProgram
SPI CRC error Menu 0x2900 (Menu poweroff) once, 0x6100 (menu charge). RF not (yet) reset when in
0x410A
menu ext. power on. Mask RF errors on Menu_ExtPowerOn
0x1180 C_ErrorDevlibNoStimBarImg
0x410D C_ErrorCpxRF01DMATEError
0x011B ERROR_BUTTON_NEVER_PRESSED
Malformed pulse, signal IPH/INH not conform. Check what's happening when stop/emerstop is received
0x00DC
exactly during pulse
0x00D4 HV too high (>195V @ anytime during module use)
When remote is preparing a communication to 1 or several modules, the target is not defined (none
selected). : 1. The menu in which the command was called missed a check on number of modules. Menu
0x4904
is 0xf0203, C_MenuId_RfTest, only accessible from menu_rd !!! Check if this error could have been raised
before buy. If not, hide the Menu RD
0x4102 C_ErrorCpxRF01HwFault
0x0200 Bug with "pausing mi-scan". miscan not deinitialized when pausing it
0x4753 side effects of 0x480B
0x4737 side effects of 0x480B
0x3001 C_ErrorRecordVerify
0x271C Jump sent to a wrong program ID
Error are defined as being abnormal parameter or behavior of the module (including both hardware and software issues)
which firmware can't recover from in a safe and functional way. The increase of error will stop all safety critical process, and
store a 16bits error code will flag the abnormal parameter or behavior of the module (including both hardware and
software issues). The initialization self-tests will also generate an error code. If the paired RC is in range, the module will
communicate the error code.
38
Part to change
Remote
Remote
Remote
Remote FW
Module
Module (80/20
FW vs HW)
Module FW
Remote
