THEORY OF OPERATION
DIAGRAM SYSTEM OVERVIEW
The figure below shows the interaction between the systems and subsystems during an electrostimulation session. The
modules transmit the electrical signal via the electrodes placed on the skin. The electrical signal is controlled by the remote
(wireless connection).
Electrostimulation Commands
Battery
Interface Subsystem
Figure 2 : Electrostimulation session diagram
11
Battery Pod
Electrode
Stimulation
Electrode
Pod
Human
Skin
