SPECIFICATION

GLOBAL SPECS

Operating conditions
Temperature: 0° C to 40° C (32 °F to 104 °F)
-
Relative Humidity: 30% to 75%
-
Atmospheric Pressure: 700hPa to 1060hPa
-
Storage and transportation conditions:
Temperature: - 20° C to +45°C (-4 °F to 113 °F)
-
Relative Humidity: max 75%
-
Atmospheric Pressure: 700hPa to 1060hPa
-
The remote control has a LCD TFT 320X240 pixels display of 2.4'' to 2.6''. Elements can be displayed using any colors
comprised in a color space of 65K colors (R:5-bit, G:6-bit, B:5-bit).
Battery
Remote control battery: Lithium Polymer (LiPo) rechargeable 3.7[V] / ≥ 1500[mAh].
Module battery:
AC adaptor: Only AC adaptor 5[V] / 3.5[A] bearing the part number 649028 can be used to recharge the Wireless
Professional device.
The device is made to be recharged whatever is the state of the battery. There's no need to empty the batteries (of the
remote or the modules) to charge them back.
NOTE: For the remote control and the modules battery maintenance, refer to the MAINTENANCE chapter of this document.
RF data
Frequency band of emission and reception: 2.4 [GHz] ISM (2.4-2.4835 [GHz])
Modulation type and frequency characteristics: GFSK, +/- 320 [kHz] deviation
Effective radiated power: 4.4 [dBm]
Chattanooga® Revolution Wireless may be interfered by other equipment, even if that other equipment complies with
CISPR EMISSION requirements.
Electrical characteristics
Without specific information, all electrical specifications are given for an impedance of 500-1000 [Ω] per channel.
Channels: Four independent and individually adjustable channels electrically insulated from each other.
For the Chattanooga® Revolution Wireless, the waveform is limited to "Square Biphasic Symmetric – 1 pulse with a 100usec
interval". The output waveforms are constant current, square shape and zero net DC.
Lithium Polymer (LiPo) rechargeable 3.7[V] / ≥ 450[mAh].
