Replacing the Drive Belt
exxentric.com/support
KBOX MAINTENANCE (cont.)
Remove the end of the Belt attached to the axle as
described above, push the Belt Adjustment Lever and pull
that end of the Belt through the opening in the platform.
Follow these steps to complete the replacement:
1. Push out the pin holding the Drive Belt in the shaft using
the Locking Pin Removal Tool provided in the toolbag.
2. Remove Belt from the shaft and Pulley. Make a knot on
the Belt.
3. Flip kBox over. Take out all of the Belt from the Auto
retract, disconnect and fix the hook on the short strand
to the kBox so spring can't retract.
4. Remove the old Belt completely. Take a new Belt and
attach it to the short strand and let it slide in gently into
the Auto retract.
5. Take the free end through the holes in the chassis and
the locking mechanism and make a knot. Flip kBox back.
6. Put Belt through Pulley and Shaft. Lock it in the shaft with
the pin.
Video: ​ h ttps://youtu.be/fkdpURmWK30
