6.4 DeviceNet Physical Layer and Media
Table 6-9. Micro-Style DeviceNet Connector Pinout Legend
70
Item Description
A Male Connector (pins)
B Female Connector (sockets)
1 Drain (bare)
2 V+ (red)
3 V- (black)
4 CAN_H (white)
5 CAN_L (blue)
