3.1 Controller Installation
200.5
14.0
27.4
8X M3 x 6MM
8.1
44.9
16.0
6.6
Figure 3-2. Panel-Mounting the SmartController EX Motion Controller (Units in mm)
Table-Mounting the SmartController EX Motion Controller
To table-mount the controller, install two brackets on each side near the bottom of the unit, as
shown in the following figure. These brackets must be ordered separately. They do not come
with the controller.
18
4X 40356-00000
273.9
R3.6 TYP.
44.9
346.6
359.8
SmartController EX User's Guide
16.1
11069-000 Rev. H
