Figure 3-3. Table-Mounting the SmartController EX Motion Controller (Units in mm)
Stack-Mounting Components
To stack-mount the SmartController EX motion controller and a compatible unit, such as a
SmartVision MX vision controller, install two brackets on each side of the units, as shown in
the following figure. These brackets are supplied with compatible units.
11069-000 Rev. H
R3.6
24.1
378.6
391.8
4X M3 x 6MM
SmartController EX User's Guide
12.1
16.2
120.9
Chapter 3: Installation
21.6
16.0
19
