3.1 Controller Installation
150.0
186.5
Figure 3-4. Stack-Mounting SmartController EX Motion Controller (Units in mm)

Memory Card

The SmartController EX motion controller is equipped with a Secure Digital
card. The SD card is removable, and can be moved to another SmartController EX motion con-
troller for testing.
The SD card shipped with all systems is factory-configured and installed. The SD card stores
the eV+ operating system, application programs, data files, and licenses.
Only the factory-supplied SD card will work with the SmartController EX motion controller.
NOTE: This SD card is not compatible with the legacy SmartController CX or
CS motion controllers.
20
15.0 52.0
162.0
SmartController EX User's Guide
14393-000
328.9
225.0
™
(SD) memory
11069-000 Rev. H
