5.2  Front Panel Dimensions

5.2 Front Panel Dimensions

55.9
16.5
56
38.7
76.2
6.4
Figure 5-2. Front Panel Dimensions (Units in mm)
SmartController EX User's Guide
152.4
88.9
13.1
129.5
4x M4 x 18 mm
6.4
139.7
30
11069-000 Rev. H
