7-24 C 7: M
HAPTER ANAGEMENT

Software Upgrade

U W I
SING THE EB NTERFACE
This page is used to upgrade the management software on the hubs in
the stack with a new agent software upgrade, as shown in Figure 7-15.
You must copy the new software upgrade into the appropriate
directory on the TFTP server that the server has been configured to look
in. For information on how to use your TFTP server, refer to the
documentation that accompanies it.
When a hub is upgraded, any configurations that have been made to it
are maintained. Upgrading a stack of hubs may take up to 5 minutes
for each hub.
Software Upgrade Page
Figure 7-15
The fields are:
Filename Type the filename of the upgrade file. Do not enter a path.
The file name format is:
PS Hub 40 software upgrade —
PS Hub 50 software upgrade —
Where xx_yy is the version of agent software. You can specify multiple
file names (separated by spaces), to upgrade PS Hub 40 and
PS Hub 50 units in the stack at the same time, for example:
psh02_00.bin psf02_00.bin
Server Address Enter the address of the TFTP server that has the
software upgrade on it.
xx_yy
psh .bin
xx_yy
psf .bin
DUA1640-5AAA02
