Quick Config
Manager
Through the Console
Port
DUA1640-5AAA02
To do this for Netscape Navigator:
1 Start Netscape Navigator.
2 From the Options menu, select Network Preferences.
The preferences dialog box appears.
3 Check the 'Every Time' checkbox.
4 Click OK.
To do this for Microsoft Internet Explorer:
1 Start Microsoft Internet Explorer.
2 From the View menu, select Options.
The Options dialog box appears.
3 Select the Advanced tab, and in the Advanced property sheet click
Settings.
4 Check the 'Every visit to the page' checkbox.
5 Click OK.
You can manage the PS Hub using Quick Config Manager. You can
manage the hub:

Through the console port

Over the network — Windows '95 and Windows NT (version 4 or
later) only
You can perform similar management functions using Quick Config
Manager as you can using the web interface.
You need to use a null modem cable for connecting your management
station directly to the console port. This should be available from your
supplier. There are a variety of null modem cables that you can use. For
an example of one of these, refer to "Console Cable" on page A-4.
Connect one end of the null modem cable to the console port on the
hub, and the other to the serial (RS232) port on your management
station with Quick Config Manager installed.

Quick Config Manager

5-13
