7-4 C 7: M
HAPTER ANAGEMENT
About the
Web Interface

General Components

U W I
SING THE EB NTERFACE
The web interface has been designed so that it is easy to use. It is
made up of three areas, as shown in Figure 7-3; the banner, side bar
(always displayed) and page (changes to show the different information
about the stack).
Components of the Web Interface
Figure 7-3
If you click on the:
Management categories (on the side bar) — The page area changes
to show different management information about the stack, for
example network addresses and graphs.
External links (on the banner) — The web browser displays general
information which is external to the web interface, for example help
and contact information.
DUA1640-5AAA02
