1
PANEL DESCRIPTION
Assignable Software Key functions (Continued)
Emergency
1. Hold down during the Emer SW ON Timer (Sec)
period to enter the Emergency mode.
2. After the Reminder Timer period has passed, an
Emergency call is automatically transmitted once,
or repeatedly.
NOTE:
• Set the related settings using the programming
software.
L Hold down during the Emer SW OFF Timer (Sec)
period to cancel the Emergency function, before
transmitting an Emergency call.
Group
z Push to enter the Application selection mode with
the Call Type "Group."
z While in the application selection mode, hold down
for 1 second to return to the standby screen.
Individual
z Push to enter the Application selection mode with
the Call Type "Individual."
z While in the application selection mode, hold down
for 1 second to return to the standby screen.
ID-MR Select
z Push to recall the received ID code. The transceiver
can memorize up to 5 codes, and select a desired
one using [CH Up] or [CH Down].
z Hold down for 1 second to clear the selected ID
code.
Message
1. While in the Standby mode, push to display the
Message List screen.
2. Push [CH Up] or [CH Down] to select a message.
3. Push [PTT] to send the message to the currently
selected station or group.
L See pages 5-7 for details.
Re-dial
Push to send the last transmitted DTMF code number.
L Redial will be cleared when the transceiver is turned OFF
once.
Status
<For the Simple key and Ten-key types>
z Hold down for 1 second to transmit a Status call in
the Standby mode.
z You can select a status message, as described
below.
1. Push to display the Status Message selection
screen, and then select a status message using
[CH Up] or [CH Down].
2. Push [PTT] to transmit a Status call.
<For the Non-Display type>
Hold down for 1 second to transmit a Status call.
L See page 5-6 for details.
Status Up, Status Down
z While in the Standby mode, push to select a status
message.
z When a received message is displayed:
• Push to cancel the automatic scroll.
• Push to manually scroll the message that contains
more than 8 characters.
TX Code Enter
Push to enter the TX Code edit mode (5-Tone).
1-11
