Icom IC-F21S Instruction Manual
Hide thumbs Also See for IC-F21S:

Advertisement

Quick Links

SAFETY TRAINING INFORMATION
Your Icom radio generates RF electromagnetic
energy during transmit mode. This radio is de-
signed for and classified as "Occupational Use
Only", meaning it must be used only during the
course of employment by individuals aware of the
W ARN ING
hazards, and the ways to minimize such hazards.
This radio is NOT intended for use by the "General Popula-
tion" in an uncontrolled environment.
This radio has been tested and complies with the FCC RF expo-
sure limits for "Occupational Use Only." In addition, your Icom radio
complies with the following Standards and Guidelines with regard to
RF energy and electromagnetic energy levels and evaluation of
such levels for exposure to humans:
• FCC OET Bulletin 65 Edition 97-01 Supplement C, Evaluating
Compliance with FCC Guidelines for Human Exposure to Radio
Frequency Electromagnetic Fields.
• American National Standards Institute (C95.1 – 1992), IEEE Stan-
dard for Safety Levels with Respect to Human Exposure to Radio
Frequency Electromagnetic Fields, 3 kHz to 300 GHz.
• American National Standards Institute (C95.3 – 1992), IEEE Rec-
ommended Practice for the Measurement of Potentially Hazardous
Electromagnetic Fields – RF and Microwave.
To ensure that your exposure to RF electromag-
netic energy is within the FCC allowable limits for
occupational use, always adhere to the following
C AU TIO N
guidelines:
• DO NOT operate the radio without a proper antenna attached, as
this may damage the radio and may also cause you to exceed FCC
RF exposure limits. A proper antenna is the antenna supplied with
i
this radio by the manufacturer or an antenna specifically authorized
by the manufacturer for use with this radio.
• DO NOT transmit for more than 50% of total radio use time ("50%
duty cycle"). Transmitting more than 50% of the time can cause
FCC RF exposure compliance requirements to be exceeded. The
radio is transmitting when the "TX indicator" lights red. You can
cause the radio to transmit by pressing the "PTT" switch.
• ALWAYS use Icom authorized accessories (antennas, batteries,
belt clips, speaker/mics, etc). Use of unauthorized accessories can
cause the FCC RF exposure compliance requirements to be ex-
ceeded.
• ALWAYS keep the antenna at least 2.5 cm (1 inch) away from the
body when transmitting and only use the Icom belt-clips, listed in p. 22,
when attaching the radio to your belt, etc., to ensure FCC RF ex-
posure compliance requirements are not exceeded. To provide the
recipients of your transmission the best sound quality, hold the an-
tenna at least 5 cm (2 inches) from mouth, and slightly off to one
side.
The information listed above provides the user with the information
needed to make him or her aware of RF exposure, and what to do to
assure that this radio operates within the FCC RF exposure limits of this
radio.
Electromagnetic Interference/Compatibility
During transmissions, your Icom radio generates RF energy that
can possibly cause interference with other devices or systems. To
avoid such interference, turn off the radio in areas where signs are
posted to do so. DO NOT operate the transmitter in areas that are
sensitive to electromagnetic radiation such as hospitals, aircraft,
and blasting sites.
ii

Advertisement

Table of Contents
loading

Summary of Contents for Icom IC-F21S

  • Page 1 • ALWAYS keep the antenna at least 2.5 cm (1 inch) away from the such levels for exposure to humans: body when transmitting and only use the Icom belt-clips, listed in p. 22, • FCC OET Bulletin 65 Edition 97-01 Supplement C, Evaluating when attaching the radio to your belt, etc., to ensure FCC RF ex-...
  • Page 2: Table Of Contents

    The use of non-Icom battery packs/chargers may impair transceiver performance and invalidate the warranty. FCC caution: Changes or modifications to this transceiver, not expressly approved by Icom Inc., could void your authority to op- erate this transceiver under FCC regulations.
  • Page 3: Panel Description

    2CH version 16CH version e DEALER-PROGRAMMABLE KEY [Upper] CH1 CH2 CH1 to CH16 Can be programmed for one of several functions by your Icom dealer. r PTT SWITCH [PTT] Push and hold to transmit; release to receive. t DEALER-PROGRAMMABLE KEY [Lower] Can be programmed for one of several functions by your Icom dealer.
  • Page 4: Led Indicator

    ACCESSORIES PANEL DESCRIPTION ‘ ‘ LED indicator ‘ ‘ Accessory attachment D Supplied accessories The TX/RX indicator LED indicates several more information as follows; The transceiver comes supplied with the following accessories. (Ref.; R=Red, G=Green, O=Orange) q Flexible antenna w Belt clip •...
  • Page 5: Battery Packs

    BATTERY PACKS BATTERY PACKS ‘ ‘ Battery cautions ‘ ‘ Battery pack replacement • CAUTION! NEVER short the terminals of the battery pack (or Before replacing the battery pack, the volume control MUST be ro- charging terminals of the transceiver). Also, current may flow into tated fully counterclockwise, nearby metal objects such as a necklace, so be careful when plac- until a click is heard, to turn the...
  • Page 6: Battery Charging

    BATTERY PACKS BATTERY PACKS D Rapid charging with the BC-144+AD-99 ‘ ‘ Battery charging Turn power OFF D Rapid charging with the BC-144+AD-99 The optional BC-144 provides rapid charging of optional battery BP-209, BP-210 or BP-222 attached packs. to the transceiver. The following are additionally required: •...
  • Page 7: Charging Note

    BATTERY PACKS BATTERY PACKS D Rapid charging with the BC-121+AD-99 ‘ ‘ Charging NOTE The optional BC-121 allows up to 6 battery packs to be charged si- Prior to using the transceiver for the first time, the battery pack must multaneously.
  • Page 8: Battery Case (Option)

    PROGRAMMABLE FUNCTIONS BATTERY PACKS ‘ ‘ Battery case (Option) ‘ ‘ General When using a BP-208 OPTIONAL BATTERY CASE attached to the In the following explanations, programmable function names are transceiver, install 6 AA (R6) size alkaline batteries as illustrated bracketed, the specific switch used to activate the function depends below.
  • Page 9 PROGRAMMABLE FUNCTIONS PROGRAMMABLE FUNCTIONS D D SCAN FUNCTION D D MONITOR AUDIBLE FUNCTION The scan function allows you to search a pre-programmed group The monitor function allows you to open the transceiver’s squelch of channels for signals. manually to check whether a channel is busy or not. The trans- ceiver has 2 conditions for receive standby: Push the [Scan] switch to start/stop scan.
  • Page 10 PROGRAMMABLE FUNCTIONS PROGRAMMABLE FUNCTIONS D D DTMF TRANSMISSION D D CODE SQUELCH This function allows you to send a pre-programmed DTMF code to This conveniently eliminates unwanted audio and is useful in group control a repeater, open another transceiver’s squelch, etc. activities or security related activities where unwanted output can be a problem.
  • Page 11: Conventional Operation

    CONVENTIONAL OPERATION CONVENTIONAL OPERATION ‘ ‘ Receiving and transmitting ‘ ‘ Call procedure NOTE: Transmitting without an antenna may damage the trans- When your system employs tone signalling (excluding CTCSS and ceiver. See p.4 for antenna attachment. DTCS), the call procedure may be necessary prior to voice trans- Turn power ON as described on p.
  • Page 12: Transmitting Notes

    CLONING CONVENTIONAL OPERATION ‘ ‘ Transmitting notes ‘ ‘ Cloning D D TIME-OUT TIMER Cloning allows you to quickly and easily transfer the programmed After continuous transmission for a pre-programmed period, the contents from one transceiver to another transceiver; or data from time-out timer is activated, causing the transceiver to stop transmit- PC to a transceiver using the optional CS-F11 CLONING SOFT-...
  • Page 13 OPTION OPTION D D OTHER OPTIONS ‘ ‘ Options • HM-46L/HM-75A/HM-131L SPEAKER-MICROPHONES Combination speaker-microphone that provides convenient oper- D D BATTERY PACKS ation while hanging the transceiver from your belt. • BP-208 BATTERY CASE HM-75A has programmable function key Mic Up, Mic Down, Mic Allows a set of Alkaline batteries to operate the handheld when A, Mic B.
  • Page 14 (1) This de- vice may not cause harmful interference, and (2) this device must accept any interference received, including in- terference that may cause undesired operation. IC-F11/F21S series A-6021H-1EX Printed in Japan 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003 Japan © 2001 Icom Inc.
