INSTRUCTION MANUAL
VHF TRANSCEIVER
iF11/S
UHF TRANSCEIVER
iF21/S
This device complies with Part 15 of the FCC rules. Oper-
ation is subject to the following two conditions: (1) This de-
vice may not cause harmful interference, and (2) this
device must accept any interference received, including in-
terference that may cause undesired operation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IC-F11S and is the answer not in the manual?

Questions and answers

Related Manuals for Icom IC-F11S

Summary of Contents for Icom IC-F11S

  • Page 1 INSTRUCTION MANUAL VHF TRANSCEIVER iF11/S UHF TRANSCEIVER iF21/S This device complies with Part 15 of the FCC rules. Oper- ation is subject to the following two conditions: (1) This de- vice may not cause harmful interference, and (2) this device must accept any interference received, including in- terference that may cause undesired operation.

  • Page 2: Safety Training Information

    This radio has been tested and complies with the FCC RF expo- sure limits for “Occupational Use Only.” In addition, your Icom radio complies with the following Standards and Guidelines with regard to RF energy and electromagnetic energy levels and evaluation of such levels for exposure to humans: •...
  • Page 3 • ALWAYS keep the antenna at least 2.5 cm (1 inch) away from the body when transmitting and only use the Icom belt-clips, listed in p. 22, when attaching the radio to your belt, etc., to ensure FCC RF ex- posure compliance requirements are not exceeded.

  • Page 4: Foreword

    The use of non-Icom battery packs/chargers may impair transceiver performance and invalidate the warranty. FCC caution: Changes or modifications to this transceiver, not expressly approved by Icom Inc., could void your authority to op- erate this transceiver under FCC regulations.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS SAFETY TRAINING INFORMATION ..... . .i-ii FOREWORD ......... .iii IMPORTANT .

  • Page 6: Panel Description

    PANEL DESCRIPTION ‘ ‘ Switches, controls, keys and connectors 2CH version 16CH version CH1↔CH2 CH1 to CH16 Speaker...
  • Page 7 VOLUME CONTROL [OFF/VOL] Turns power ON and adjusts the audio level. e DEALER-PROGRAMMABLE KEY [Upper] Can be programmed for one of several functions by your Icom dealer. r PTT SWITCH [PTT] Push and hold to transmit; release to receive.

  • Page 8: Led Indicator

    PANEL DESCRIPTION ‘ ‘ LED indicator The TX/RX indicator LED indicates several more information as follows; (Ref.; R=Red, G=Green, O=Orange) • TX: Turns Red while transmitting a signal. • RX: Turns Green while receiving a signal. • Call LED (ON): When receiving a matched 2/5TONE. •...

  • Page 9: Accessories

    ACCESSORIES ‘ ‘ Accessory attachment D Supplied accessories The transceiver comes supplied with the following accessories. q Flexible antenna w Belt clip D Antenna The antenna screws onto the transceiver as illustrated right. D Belt clip Attach the belt clip to the transceiver as illustrated below.

  • Page 10: Battery Packs

    BATTERY PACKS ‘ ‘ Battery pack replacement Before replacing the battery pack, the volume control MUST be ro- tated fully counterclockwise, until a click is heard, to turn the power OFF. • Push the battery release for- ward, then pull the battery pack upward with the trans- ceiver facing you.

  • Page 11: Battery Cautions

    ‘ ‘ Battery cautions • CAUTION! NEVER short the terminals of the battery pack (or charging terminals of the transceiver). Also, current may flow into nearby metal objects such as a necklace, so be careful when plac- ing battery packs (or the transceiver) in handbags, etc. Simply carrying with or placing near metal objects such as a neck- lace, etc.

  • Page 12: Battery Charging

    BATTERY PACKS ‘ ‘ Battery charging D Rapid charging with the BC-144+AD-99 The optional BC-144 provides rapid charging of optional battery packs. The following are additionally required: • One AD-99 (depends on version.). • An AC adapter (may be supplied with the BC-144 depending on version).
  • Page 13 D Rapid charging with the BC-144+AD-99 BP-209, BP-210 or BP-222 attached to the transceiver. AC adaptor BC-145A/E/V/UK Charging indicator D D Spacer combination. • Be sure to attach the spacer (Spacer B/C) to the adapter (Spacer A) with the orientation as il- lustrated in the diagram at right.
  • Page 14 BATTERY PACKS D Rapid charging with the BC-121+AD-94 (#11) The optional BC-121 allows up to 6 battery packs to be charged si- multaneously. The following are additionally required. • Six AD-94 (#11) (Some versions require additional AD-99s). • An AC adapter (may be supplied with the BC-121 depending on version).

  • Page 15: Charging Note

    ‘ ‘ Charging NOTE Prior to using the transceiver for the first time, the battery pack must be fully charged for optimum life and operation. • Recommended temperature range for charging: +10°C to +40°C (50°F to 140°F). • Use the supplied charger or optional charger (BC-119/BC-121/BC- 144 for rapid charging, BC-146 for regular charging) only.

  • Page 16: Battery Case (Option)

    BATTERY PACKS ‘ ‘ Battery case (Option) When using a BP-208 OPTIONAL BATTERY CASE attached to the transceiver, install 6 AA (R6) size alkaline batteries as illustrated below. NOTE: Output power is automatically reduced to 1 W to retain suffi- cient power in case of an emergency, etc.

  • Page 17: 4 P P R R O O G G R R A A M M M M A A B B L L E E F F U U N N C C T T I I O O N N S S

    PROGRAMMABLE FUNCTIONS ‘ ‘ General In the following explanations, programmable function names are bracketed, the specific switch used to activate the function depends on programming. D D KEY LOCK FUNCTION1/2 This function locks access to all programmable switches (except the switch assigned for the lock function): Lock1: All Key Lock (except Lock key).
  • Page 18 PROGRAMMABLE FUNCTIONS D D SCAN FUNCTION The scan function allows you to search a pre-programmed group of channels for signals. Push the [Scan] switch to start/stop scan. • Scan pauses on a channel when receiving a signal. • “Lockout SCAN” (pre-programmed list SCAN) or “Priority SCAN” can be pre-programmed.
  • Page 19 D D MONITOR AUDIBLE FUNCTION The monitor function allows you to open the transceiver’s squelch manually to check whether a channel is busy or not. The trans- ceiver has 2 conditions for receive standby: All signals are received Only signals con- taining the proper tone are received D D TALK AROUND...
  • Page 20 PROGRAMMABLE FUNCTIONS D D DTMF TRANSMISSION This function allows you to send a pre-programmed DTMF code to control a repeater, open another transceiver’s squelch, etc. Automatic pre-programmed transmission: Push the [DTMF Autodial] switch to send a DTMF code. D D EMERGENCY FUNCTION The emergency function allows you to send your ID quickly and easily to your Base Station, etc.
  • Page 21 PROGRAMMABLE FUNCTIONS D D CODE SQUELCH This conveniently eliminates unwanted audio and is useful in group activities or security related activities where unwanted output can be a problem. The function is similar to a CTCSS tone squelch. In order to use the above functions, cloning is necessary via a PC using the optional CS-F11 cloning software.

  • Page 22: Conventional Operation

    CONVENTIONAL OPERATION ‘ ‘ Receiving and transmitting NOTE: Transmitting without an antenna may damage the trans- ceiver. See p.4 for antenna attachment. Turn power ON as described on p. 2. Receiving: q Select a desired channel. w Listen for a transmission and adjust [VOL] to a comfortable lis- tening level.

  • Page 23: Call Procedure

    ‘ ‘ Call procedure When your system employs tone signalling (excluding CTCSS and DTCS), the call procedure may be necessary prior to voice trans- mission. The tone signalling employed may be a selective calling system which allows you to call specific station(s) only and prevent unwanted stations from contacting you.

  • Page 24: Transmitting Notes

    CONVENTIONAL OPERATION ‘ ‘ Setting squelch level The squelch circuit mutes the received audio signal depending on the signal strength. q While pushing [PTT] and [Lower], turn the transceiver’s power on to enter the squelch adjustment mode. w Push [Upper] to increase the squelch level (tight squelch) or [Lower] to decrease the squelch level (loose squelch).

  • Page 25: Cloning

    ‘ ‘ Cloning Cloning allows you to quickly and easily transfer the programmed contents from one transceiver to another transceiver; or data from PC to a transceiver using the optional CS-F11 WARE. D D Transceiver-to-transceiver cloning NOTE: ‘Transceiver-to-transceiver cloning’ is available be- tween the same models on 2CH model to 16CH model or the opposite case cannot be cloned.

  • Page 26: Option

    OPTION ‘ ‘ Options D D BATTERY PACKS • BP-208 BATTERY CASE Allows a set of Alkaline batteries to operate the handheld when charging the rechargeable battery or in emergencies, etc. 6 AA (R6) cells are required. • BP-209 Ni-Cd BATTERY PACK 7.2 V/1100 mAh Ni-Cd battery pack, allows more than 8 hours op- eration.

  • Page 27: Option

    D D OTHER OPTIONS • HM-46L/HM-75A/HM-131L SPEAKER-MICROPHONES Combination speaker-microphone that provides convenient oper- ation while hanging the transceiver from your belt. HM-75A has programmable function key Mic Up, Mic Down, Mic A, Mic B. HM-131L has a moisture proof construction. •...
  • Page 28 Count on us! IC-F11/F21S series A-6021H-1EX-q Printed in Japan 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003 Japan © 2001 Icom Inc.
