This manual was edited to give some indications
on the operation of the welder and was thought to
offer information for its practical and secure use.
Its purpose is not teach welding techniques. All
given suggestions are indicative and intended to
be only guidelines.
To ensure that your welder is in good condition,
inspect it carefully when you remove it from its
packing having care to ascertain that the cabinet or
the stocked accessories are not damaged.
Your welder is capable of daily activity of construction
and reparation. Its simplicity and versatility and its
excelling welding characteristics are granted by the
inverter technology. This welding inverter allows to
be finely set to obtain optimal arc characteristics with
a reduced consumption of energy and with respect
to the welders based on a traditional transformer.
Respect the duty cycle of the welder making reference to
the technical data label on the welder's back/bottom.
Duty cycle is given as percentage on a 10 minute time.
During this period of time the unit can be used at a
defined power regulation. Duty cycle exceeding may
cause overheating or welder's damage.

MAIN FEATURES

Your welder is a multiprocess unit capable of exe-
cellent performances in TIG, MMA and MIG/MAG
welding. Main features are:
Electrodes:
Your welder can weld electrodes ø 1,6 ÷ 6mm,
6011, 6013, 7018, cast iron.
Welding Wire Selection:
Your welder can work with Aluminum wire 0,8÷1,2
thick, solid steel wire 0,6÷1,0 thick and stainless
steel wire 0,8÷1,0 thick.
Feed Rolls:
Wide selection of rolls made special for different
welding wires and diameters. Grooves available
from 0,6 till 1,2.

INTRODUCTION

Gas Selection:
According to the material to be welded and to the
wire you are going to use select the shielding gas.
The here below table can give you some useful in-
dications:
Table 1
MIG 2x
MIG
EN-3
MATERIAL TO
WELD CYLINDER
Argon + CO2
Mild steel
cylinder or CO2
Argon 98% +
Stainless steel
CO2 2%
Aluminium
Brazing Alloys
GAS
WIRE
Copper
coated mild
steel
Stainless steel
Argon Aluminium
Argon Brazing wire
