Introduction
The Mobile Industry Processor Interface (MIPI)
Camera Serial Interface (CSI-2) RX subsystem
implements a CSI-2 receive interface according
to the MIPI CSI-2 standard v2.0
underlying MIPI D-PHY standard v1.2. The
subsystem captures images from MIPI CSI-2
camera sensors and outputs AXI4-Stream video
data ready for image processing. The
subsystem allows fast selection of the top level
parameters and automates most of the lower
level parameterization. The AXI4-Stream video
interface allows a seamless interface to other
AXI4-Stream-based subsystems.

Features

• Support for 1 to 4 D-PHY lanes
• Line rates ranging from 80 to 2500Mb/s
• Multiple Data Type support (RAW, RGB, YUV)
• AXI IIC support for Camera Control
Interface (CCI)
• Filtering based on Virtual Channel Identifier
• Support for 1, 2, or 4 pixels per sample at
the output as defined in the Xilinx
AXI4-Stream Video IP and System Design
Guide (UG934) [Ref 2]
• AXI4-Lite interface for register access to
configure different subsystem options
• Dynamic selection of active lanes within the
configured lanes during subsystem
generation.
• Interrupt generation to indicate subsystem
status information
• Internal D-PHY allows direct connection to
image sources
MIPI CSI-2 RX Subsystem v4.0
PG232 July 02, 2019
[Ref 1] with
format
www.xilinx.com
• Support for MIPI CSI-2 standard v2.0
features such as VCX, RAW16, and RAW20
IP Facts Table
Subsystem Specifics
Supported
(1)
Device Family
Supported User
Interfaces
Resources Performance and Resource Utilization web page
Provided with Subsystem
Design Files
Example Design
Test Bench
Constraints File
Simulation
Model
Supported
(2)
S/W Driver
Tested Design Flows
Design Entry
Simulation
Xilinx Design Tools: Release Notes
Synthesis
Support
Provided by Xilinx at the
Notes:
1. For a complete list of supported devices, see the Vivado IP
catalog.
2. Standalone driver details can be found in the SDK directory
(<install_directory>/SDK/<release>/data/embeddedsw/doc/
xilinx_drivers.htm). Linux OS and driver support information
is available from the
Xilinx Wiki page.
3. For the supported versions of the tools, see the
Xilinx Design Tools: Release Notes

IP Facts

UltraScale+™,
Zynq® UltraScale+ MPSoC,
Zynq®-7000 SoC,
7 Series FPGAs
AXI4-Lite, AXI4-Stream
Encrypted RTL
Vivado IP Integrator
Not Provided
Not Provided
Standalone and Linux
(3)
Vivado® Design Suite
For supported simulators, see the
Guide.
Vivado Synthesis
Xilinx Support web page
Guide.
