Table 2-5: Port Descriptions (Cont'd)
Signal Name
video_out_tready
video_out_tuser[n-1:0]
video_out_tlast
video_out_tdata[n-1:0]
video_out_tdest[9:0]
AXI4-Stream Interface when Embedded Non-image Interface is Selected
emb_nonimg_tdata[n-1:0]
emb_nonimg_tdest[3:0]
emb_nonimg_tkeep[n/8-1:0]
emb_nonimg_tlast
emb_nonimg_tready
MIPI CSI-2 RX Subsystem v4.0
PG232 July 02, 2019
Direction
Input Slave ready to accept the data
n is based on TUSER width selected in the Vivado IDE
95-80 CRC
79-72 ECC
71-70 Reserved
69-64 Data Type
Output 63-48 Word Count
47-32 Line Number
31-16 Frame Number
15-2 Reserved
1 Packet Error
0 Start of Frame
Output End of line
Data
Output
n is based on Data type and number of pixels selected in the
Vivado IDE (see
9-4 Data Type
Output
3-0 Virtual Channel Identifier (VC)
Data
output
n is based on Data type selected in the Vivado IDE (see
Table 1-1).
Specifies the Virtual Channel Identifier (VC) value of the
Output
embedded non-image packet
Output Specifies valid bytes
Output End of line
Input Slave ready to accept data
www.xilinx.com
Chapter 2: Product Specification
Description
(3)
(2)
video_out Port Width).
