Introduction
Note: Parts of this document contain information in languages other than English. This is required for
regulatory compliance.
This document provides hardware and software installation procedures for the Varium™ C1100
compute adaptor using XRT 2020.2.1.
Different system configurations are available for running, developing, and debugging applications
on your Varium C1100 compute adaptor:
• Running Applications: To configure a system to run accelerated applications, install a Varium
C1100 compute adaptor into a system as described in
Procedures
along with the required deployment software to support running applications.
• Running, Developing, and Debugging Applications: By installing the Varium C1100 compute
adaptor with both the deployment and development software on a single machine, you can
configure a system for developing and running compute applications. With the adaptor
installed, developers can debug applications in both emulation modes and on the hardware.
Adaptor Features
The full-height, half-length Varium C1100 compute adaptor is Gen3 x16 PCI Express
compliant. It features the Xilinx
The Varium C1100 compute adaptor features are as follows.
Table 1: Varium C1100 Compute Adaptor Features
Adaptor Component
FPGA
HBM
Network Interface
PCIe
I2C Bus
UG1525 (v1.0) September 17, 2021
Varium C1100 Compute Adaptor Installation Guide
®
UltraScale+™ architecture and targets compute applications.
UltraScale+™ XCU55N FPGA
8 GB - two 4 gigabyte (GB) HBM memory stacks
2 x QSFP28 supporting 100 GbE, 40 GbE, or 4 x 10/25 GbE
Status LEDs
16-lane PCI Express
PCIe integrated endpoint block connectivity
Gen1, 2, or 3 up to x16, Gen4 x8
Dual Gen4 x8
Chapter 1: Introduction
Chapter 1
Chapter 3: Adaptor Installation
Varium C1100
✓
Send Feedback
®
(PCIe)
www.xilinx.com
5
