SYS Node-ID
Data Set
Parameter Number
No. of Bytes (Int)
Value
SYS
ASCII
0
Hex-Values 30
ExOR function over all characters in the
data frame :
0x30 ^0x32 = 0x02
0x02 ^0x35 = 0x37
0x37 ^0x32 = 0x05
0x05 ^0x30 = 0x35
0x35 ^0x30 = 0x05
0x05 ^0x34 = 0x31
0x31 ^0x30 = 0x01
0x01 ^0x33 = 0x32
0x32 ^0x45 = 0x77
0x77 ^0x38 = 0x4F
0x4F ^0x03 = 0x4C
The BCC is calculated as character "L" = 0x4C.
7.3
Telegram Check / Error Acknowledgement
The frequency inverter and the bus master check the telegrams for correctness. Depending on the
type of telegram, the corresponding reaction takes place. The telegrams are checked for correct syn-
tax, address and text part (content, checksum).
In case the telegram contains errors, the frequency inverter either returns NAK or it does not respond
at all. The possible causes are listed below:
No response:
− incorrect telegram structure
− incorrect control character
− wrong address
− telegram addressed to address 32 (Broadcast); in this case the frequency inverter does not reply
NAK
See Chapter 13.1 "Warning Messages".
32
= 0
= 0x30
= 2
= 0x32
= 520 = 0x35 0x32 0x30
= 04
= 0x30 x034
= 1000 = 0x30 0x33 0x45 0x38
ds
n
n
n
2
5
2
0
32
35
32
30
a
a
w
w
0
4
0
3
30
34
30
33
Example of ExOR operation
for the first two characters :
0011 0000= 0x30
0011 0010= 0x32
---
-------
EXOR
0000 0010= 0x02
VABus Agile
w
w
ETX
E
8
-
45
38
03
Protocol
