Protocol
2. Digit d: Data set number
Digit 3 to 5: Parameter number
The block can have a maximum string length of 80 characters.
SdnnnSdnnn ... Sdnnn
Write Block
Parameter
Read Block
Parameter
The data block is a string containing the values of the parameters in an ASCII-Hex form in succession.
The maximum string length is 80 characters, enabling the transmission of blocks of up to 20 parame-
ters of the type "word" (each with 4 Hex digits). If the block contains parameters of the type double
word (each with 8 Hex digits) the number of parameters which can be transmitted in a block is re-
duced accordingly.
Examples of a block transfer
Read parameters
each from data set 0.
Parameter string for
Parameter string for
Set Parameter 017 Master
EOT ADR STX SYS ds n n n a a w w w w w w w w w w w w w w w ETX BCC
♦
ASCII A
Hex-
04 41 02 30 30 303137 3135 30 30 32 31 30 30 3032 31 31 30 30 32 31 33 ♥
Values
Enquiry Telegram Master
EOT
♦
ASCII
Hex-Values 04
Response Frequency Inverter
ADR STX SYS ds n n n a a w w w w w w w w w w w w w w w w ETX BCC
☻
ASCII A
Hex-
02 30 30 30 31 39 31 36 30 30 30 30 32 41 35 44 30 30 36 36 30 30 32 38 ♥
41
Values
Parameter
210 Stator frequency
211 R.m.s current
213 Active power
Write the parameters
Values:
FF2 (double word = 8 hex-digits) = 123.50 Hz, 12350
FF3 (double word = 8 hex-digits) = 43.45 Hz,
Write parameter 017:
