5.4

Set the Protocol for X21-Connection and Communication Module

 395 Protocol (CM / X21)
Protocol (CM / X21)
With Parameter
Communication Module (CM) and the X21-Connection.
Protocol (CM/X21)
(CM / X21)
0 - CM: VABus / X21: VABus
1 - CM: VABus / X21: Modbus
2 - CM: Modbus / X21: VABus
6

VABus

The VABus protocol can be used via a fitting CM module or the onboard X21 connection (RJ45)
6.1

VABus on the X21-Connection

 1500 X21: VABus Baud rate
X21: VABus Baud rate
With Parameter
set. The setting applies to the X21-Connection. Parameter
"0 - CM: VABus / X21: VABus" or "2 - CM: Modbus / X21: VABus".
VABus-X21 Baud rate
1 –
2 –
3 –
4 –
5 –
6 –
7 –
Attention!
Changes to the baud rate are effective immediately. A restart of the frequency inverter is not re-
quired.
All bus participants must be set to the same baud rate.
22
395, the communication protocol can be selected for an optional
395
The slot for an optional Communication Module and the X21-
Connection (RJ45) are set to the VABus communication protocol.
Factory setting.
The slot for an optional Communication Module is set to the VABus
communication protocol. The X21-Connection (RJ45) is set to the
Modbus communication protocol.
The slot for an optional Communication Module is set to the Mod-
bus communication protocol. The X21-Connection (RJ45) is set to
the VABus communication protocol.
1500 the transfer rate of the VABus communication can be
1500
2400 Baud Transfer rate 2400 Baud
4800 Baud Transfer rate 4800 Baud
9600 Baud Transfer rate 9600 Baud
19200 Baud Transfer rate 19200 Baud
57600 Baud Transfer rate 57600 Baud
115200 Baud Transfer rate 115200 Baud
230400 Baud Transfer rate 230400 Baud
Function
Protocol (CM / X21)
Function
VABus Agile
VABus
395 must be set to
max. Line Length
30 m
30 m
30 m
30 m
10 m
10 m
10 m
