Handling of Data Sets / Cyclic Writing

8 Handling of Data Sets / Cyclic Writing
Access to the parameter values is carried out on the basis of the parameter number and the required
data set.
There are parameters the values of which exist once (data set 0) as well as parameters the values of
which exist four times (data set 1...4). These are used for data set change-over.
If parameters which exist four times in the data sets are set to data set = 0, all four data sets are set
to the same value.
A read access with data set = 0 to such parameters is only successful if all four data sets are set to
the same value. If this is not the case, error 9 = "different values in data sets" is signaled via the error
VABus SST Error Register
register
the relevant parameter (see chapter 7.3 "Telegram Check / Error Acknowledgement").
New setting requests (select telegrams) will be blocked by the error register
ter
11. For this reason, the error register must be read out, i.e. acknowledged, before a new select
telegram can be sent.
Regardless of the signal status of the error register, reading access (enquiry telegrams) is still possi-
ble.
The values are entered into the EEPROM automatically on the controller. If values are to be written
cyclically with a high repetition rate, there must be no entry into the EEPROM, as it only has a limited
number of admissible writing cycles (about 1 million cycles).
Caution!
If the number of admissible writing cycles is exceeded, the EEPROM is destroyed.
In order to avoid the destruction of the EEPROM, data which are to be written cyclically can be en-
tered in the RAM exclusively without a writing cycle on the EEPROM. In this case, the data are volatile,
i.e. they are lost when the supply voltage is switched off (Mains Off). They must be written into the
RAM again after the restart (Mains On).
The RAM writing operation is activated by increasing the number of the target data set by five.
Exceptions are the parameters
Percentage RAM
always 0.
Access to the Data Sets of the Frequency Inverter
Parameter
Data Set 0
Data Set 1
Data Set 2
Data Set 3
Data Set 4
06/2010
11. In this case, you must read out each data set separately for
Control Word
524. These parameters will be written into the RAM although their addresses are
EEPROM
0
1
2
3
4
Reference Frequency RAM
410,
RAM
5
6
7
8
9
VABus Agile
VABus SST Error Regis-
Reference
484 and
37
