TECHNICAL DATA

Processor
Compatibility
Connectivity
Weight
Dimensions
Buttons
Port
Barcode 1D and 2D Scanner
Battery Capacity
Battery Life
Power Supply
(Optional) Contactless Card
Reader (RFID)
MECHANICAL
32-bit ARM™ Cortex™ - M3 MCU
iPhone 7 Plus and iPhone 8 Plus
Lightning™ connector
Pass-through sync via USB Type-C charge/sync cable
(Optional) Bluetooth 2.0 Class 2
-SPP Serial Port Profile
Note: Use only original USB-A to USB-C cable for charging iPhone. Use only
UL approved USB adapters. The minimum requirements of USB adapters 5V
2.21A.
250g (8.81 oz.) without iOS device
93.5mm x 36.5mm x 186.5mm (3.68 " x 1.44" x 7.34")
Left and right scan buttons for print only
USB Type-C for device charge and sync
ELECTRICAL
Supports all 1D Laser or 2D High Speed Imagers.
Rechargeable Li-ion Battery 3.7V /2400 mAh
Precise battery management by Fuel Gauge
microcontroller for remaining battery capacity.
Up to 16,850 scans in a period approximately 26 hours on
full charge
DC 5V through USB Type-C
DC 5V through charging station
DC 5V through dual charging station
ISO/IEC 14443 Type-A/MIFARE:
MIFARE MINI
MIFARE CLASSIC-1K, MIFARE CLASSIC-4K
MIFARE ULTRALIGHT, ULTRALIGHT-C
MIFARE PLUS 2K/4K
MIFARE DESFire card
and others
ISO/IEC 14443 Type - B:
- Supports most cards
ISO 15693:
- Supports most cards
JIS X 6319-4:
- Compatible with FeliCa
ISO/IEC 18000-3 mode 3:
- NFC
Page 22
