Getting Started; Flashing The Stm32 Using Iar - Silicon Laboratories WF200 Quick Start Manual

2.3 Getting Started

2.3.1 Flashing the STM32 Using IAR

1. Open the IAR project "Project.eww" located in the path \WF200_driver_F429ZI_FreeRTOS-LwIP\EWARM.
2. In IAR Workspace view, open the header file "lwip_freertos.h". The project workspace is shown in the Figure 2.3.
3. In "lwip_freertos.h", change the WLAN_SSID, WLAN_PASSKEY and WLAN_SECURITY defines to the values of the access point
you want to use.
4. Open Tera Term and connect to the STLink Virtual COM port of the NUCLEO board. In the "Setup\Serial Port" panel, select
115200 for the speed.
5. "Make" the project by clicking on the appropriate icon.
6. "Download and Debug" the project by clicking on the associated icon.
7. Wait for the project to be flashed in the STM32 .
8. Once in debug mode, click on the "GO" icon.
silabs.com | Building a more connected world.
Getting Started with STM32 MCU, with FreeRTOS, and LwIP
Figure 2.3. IAR Project Workspace
QSG166: WF200 Wi-Fi Development Kit Quick Start Guide
Rev. 0.4 | 8
