1.3 SSH Connection

With MobaXterm, create and open a
• Host: silabs-pi-demo.local
• Username: pi
• Password: default_password
All the following commands will be entered in the newly open ssh console.

1.4 Wi-Fi Demos

The SD card includes demos for the two supported modes: station and access point.
Note: On first version of the SD cards, the driver must be loaded first with the following command:
sudo wfx_driver_reload

1.4.1 Station Demo

This demo configures the Raspberry Pi and WF200 to work as a Wi-Fi station which can connect to an access point. To start it run:
sudo wfx_demo_station
Note: Minimize MobaXterm window, then wait a few seconds for the Wi-Fi tool to appear.
This will launch a graphical tool named "wpa_gui" which support the following actions:
1. Scan.
2. Select the desired Wi-Fi access point.
3. Enter credentials if need be, and then add.
Once connected, it is possible to perform some traffic:
ping silabs.com
Note: With keyboard, mouse, and screen attached to the Raspberry Pi, it is possible to launch a browser by clicking the "Silicon Labs
website" icon on the desktop.
silabs.com | Building a more connected world.
session to the Raspberry Pi with the following parameters:
ssh
Figure 1.1. SSH Console
