USING YOUR INFINEA X mini

The Infinea X Mini 2D model uses a scan engine that supports two-dimensional (2D) and one dimensional
(1D) barcode symbols. The effective reading distance of the barcode reader varies depending on the
barcode size.
Barcode Scanner—1D Barcodes
To scan a 1D barcode:
1. Activate the scanner by pressing the Scan button.
2. Position the scan head near the center of the barcode. The pointer should extend outside the
edges of the barcode, as shown in the figure below.
3. Slowly pull back the unit increasing the distance between the barcode and scan head until the
scanner has read the barcode.
Infinea® X Mini User Manual
UM-00013 Rev B
15-20 cm
Figure 10: 1D Barcode Scanning
