ASSEMBLING YOUR INFINEA X mini
Integrating the iPad mini with the Infinea X mini
1.
Open the Infinea X mini by loosening the 8 Torx Screws and gently flipping open the top cover.
Slide the iPad mini* on to the lightning connector until it clicks into place.
2.
Insert the audio jack into the iOS device until it clicks into place.
3. Close the top cover, being careful not to pinch the wires, while maintaining the position of the
protective rubber bumper. Secure the cover by tightening (8) torx screws.
Infinea X Mini is molded specifically to the iPad mini 2, 3 and 4. iOS devices are not interchangeable.
1
2
3
Do not pull on the audio jack cable with excessive force or damage the wires connecting
the top and bottom covers.
Infinea® X Mini User Manual
UM-00013 Rev B
Page 15 of 31
