Infinite Peripherals INFINEA X MINI Quick Start Manual

INFINEA ®
X MINI
*Also available in black
QUICK START GUIDE
ASSEMBLY
1. Open the Infinea X Mini by
loosening the 8 Torx Screws, and
then glently flip open the top cover.
2. Slide the iPad mini onto the
lightning connector until it clicks
into place.
1
ABOUT YOUR INFINEA
10
9
8
4
8
*Features may vary by part number.
1. FRONT SPEAKER
2. iOS ON/OFF BUTTON
3. VOLUME BUTTONS
4. NOTIFICATION LEDs
5. SPEAKER TOGGLE BUTTON
3. Insert the audio jack into the iOS device until it clicks into place.
4. Carefully close the top cover.
5. Ensure to not pinch the wires, while maintaining the position of the protective rubber bumper.
6. Secure the cover by tightening (8) torx screws.
2
CAUTION: Ensure the rubber bumper is properly aligned and there are no gaps between the top and
bottom covers. Failure to do so compromises the liquid protection features of the Infinea X Mini. If you
have any questions about installation of the rubber bumper, please contact your sales representative.
X MINI
1 2
8
8
10
8
8
5
7
6
6. HOME BUTTON
7. BATTERY STATUS BUTTON
8. TORX SCREWS
9. USB PORT
10. *AMBIENT LIGHT SENSORS
3
4
5
11
3
8
16
4
8
18
11. iOS CAMERA OPENING
12. BARCODE SCANNER
13. STRAP LATCH
14. RFID ANTENNA
15. BATTERY LATCH
6
12
13
14
15
16
17
18
13
19
16. SCAN BUTTONS
17. BATTERY COMPARTMENT
18. REAR SPEAKERS
19. CHARGING STATION
CONTACTS
