Data Aire Mini dap4 Installation, Operation & Maintenance Manual page 42

13.2 Clearing Alarm History
Once the alarm has acknowledged and corrected, the flashing red alarm will cease. The alarm is now stored with the
alarm history as described in Section 4.0.
The alarm history can be cleared by doing the following:
Go to Menu K – Alarms and History in the Main Menu
Press the ENTER key. The first screen will be titled "Alarm Settings".
▼ Press the DOWN key to display the following screen:
Move the cursor by pressing the ENTER key so it flashes on the No input. To eliminate alarm history press the UP or
DOWN key to change the message to Yes.
▼ Press the ENTER key. The history is now removed.
▼ Press the ENTER key to return cursor to title block.
▼ Press the ENTER key to return to Main Menu screen.
42 • Mini dap4 User Manual
Alarm Settings
Compressor Short Cycle Yes
Reset Alarm Log: No
Alarm Screen Contact:
No Contact Message
