Data Aire Mini dap4 Installation, Operation & Maintenance Manual page 34

▼ Press the DOWN key to view the next screen:
The following will be displayed (values are for reference only):
Once a selection or selections have been made, move the cursor to the title block (Alm Output Function 3) by press-
ing the ENTER key
▼ Press the DOWN key to view the next screen.
The following will be displayed (values are for reference only):
Once a selection or selections have been made, move the cursor to the title block (Alm Output Function 4) by press-
ing the ENTER key
▼ Press the DOWN key to view the next screen.
The following will be displayed (values are for reference only):
Once a selection or selections have been made, move the cursor to the title block (Alm Output Function 5) by press-
ing the ENTER key
▼ Press the DOWN key to view the next screen:.
The following will be displayed (values are for reference only):
34 • Mini dap4 User Manual
Alm Output Function 4
No Air Flow YES
No Water Flow YES
Powered Up YES
Floor Water YES
Humidity Inhibit YES
Heat Inhibit YES
Dirty Filter YES
Alm Output Function 5
Manual Override YES
Humidity Sensor YES
Ret Air T Sensor YES
"See Tag Inside" YES
Unit in Standby YES
UPS Sunning YES
Standby Pump On YES
Alm Output Function 6
Humidity Cylinder YES
Custom Message 1 YES
Custom Message 2 YES
Custom Message 3 YES
