3.10 MENU J – FACTORY SETTINGS (factory use only)
MENU J is for setting the control to the type equipment and options ordered. This requires the Factory Level pass-
word and entry should be limited to Data Aire factory and service personnel.
In the Main Menu screen press the UP or DOWN key until "J - Factory Settings" appears and is highlighted. Press the
ENTER key.
The following will be displayed (values are for reference only):
Model:
Screen Flip Delay:
Temp Units:
Analog Output:
Fan Mode:
Fan Type:
Once inputs have been made, move the cursor (by pressing the ENTER Key) to the title box.
▼ Press the DOWN key to view the next screen.
The following will be displayed (values are for reference only):
Available Selections:
Type: Sngl Primary (single scroll compressor)
Dual Primary (dual scroll compressor)
Sngl Pri w/UnLdr (single semi-hermetic compressor w/unloading)
None (entry for chilled water units)
Delay Btw Stages: Range is from 30 to 300 seconds (delay between start of lag compressor)
Once a selection or selections have been made, move the cursor to the title block by pressing the ENTER key
▼ Press the DOWN key to view the next screen.
24 • Mini dap4 User Manual
There are four available inputs – gForce, Mini, Mini-Plus and DA Series
The range is 0 to 99 seconds (in 1 second intervals)
Fahrenheit or Centigrade
There are three choices – None, Humidify or CW Value
There are two settings – Continuous and Automatic
There are two choices – Standard or Plug Fan
System Setting
Model: MINI-PLUS
Screen Flip Delay: 3s
Temp Units: Fahrenheit
Analog Output: None
Fan Mode: Continuous
Fan Type: Std On/Off
Compressor Setting
Type: Sngl Primary
Delay Btw States: 60s
