The following will be displayed (values are for reference only):
▼ Press the DOWN key to view the next screen.
The following will be displayed (values are for reference only):
▼ Press the MENU key to return to the Main Menu. Choose another Menu by pressing the UP or DOWN keys or
press ESC to return the normal operating mode.
16 • Mini dap4 User Manual
Analog Input
Return Air Temp
Input B07:
70.8F
Analog Output 2
Chilled Water Valve
Output
8.50vdc
