Press the UP or DOWN key. The following will appear on the screen:
FACTORY SETTINGS:
TEMPERATURE: 72.0°F
DEADBAND: 2.0°F
STAGE TO STAGE: 0.3°F
HUM SETPOINT: 50%
HUM DEADBAND: 3%
ENGY SVR SETPT: 50.0°F
DEADBAND: 1.0°F
CHANGE OVER: 2.0°F
If Humidity Anticipation is turned ON in humidity setting under Menu J - Factory Settings, the following page appears
for reference (non-edit able):
To change the value of any one of the setpoint values, move the cursor by pressing the ENTER key to the desired set-
point. The cursor will flash on the input value. Press the UP or DOWN button to increase or decrease the value. Once
the desired setpoint value has been changed, press the ENTER key to move to the next setting or until the cursor is at
the top of the screen.
Exit the Setpoint Menu by pressing the ESC Key. The display screen will return to the MAIN MENU. Use the UP or
DOWN Keys to advance to another Menu or press the ESC Key to return to the normal operating mode.
Note: Changes to any Setpoint input will remain and can only be changed manually (as described above).
3.3 MENU C – CLOCK/SCHEDULER
MENU C allows programming for setting night set-back, week-end and special day schedules.
Menu C should only be used for non-critical applications where units may be cycled off without any damage
to sensitive electronic equipment. The typical application is comfort cooling where units may be shut down
during non-working hours.
11 • Mini dap4 User Manual
Setpoints
Humidity Setpoint: 50%
Humidity Deadband: 3%
Engy Svr SetPt: 50.0 F
o
Deadband: 1.0 F
o
Change Over: 2.0 F
o
(Temperature range: 65 - 85°F)
(Temperature Deadband range: 1 - 5°F)
(Stage-to-Stage range: 0.3 - 3.0°F)
(Humidity range: 25-70%)
(Humidity deadband range: 1 - 15%)
(Setpoint range: 40.0 - 60.0°F)
(Deadband range: 1.0 - 5.0°F)
(Change over range: 2.0 - 5.0°F)
Humidity Anticipation Setpoints
Humidity Setpoint: 50%
Temperature Offset: 3%
Anticipation SP: 5.3%
