Data Aire Mini dap4 Installation, Operation & Maintenance Manual page 22

▼ Press the ENTER key to move the cursor. The cursor will flash at the Offset. By pressing the UP (to increase) or
DOWN (to decrease) keys the Offset can be changed.
Once the change has been made, press the ENTER key and the cursor will move to the upper portion of the screen.
The Offset change is now entered and stored.
To move to the next screen, press the DOWN key.
The following will be displayed (values are for reference only):
▼ Press the ENTER key to move the cursor. The cursor will flash at the Offset. By pressing the UP (to increase) or
DOWN (to decrease) keys the Offset can be changed.
Once the change has been made, press the ENTER key and the cursor will move to the upper portion of the screen.
The Offset change is now entered and stored.
▼ Press the UP or DOWN key to move to another screen or if all calibrations are completed, with the cursor flashing
in the title box, press the ESC key. This will take you to the Main Menu.
Use the UP or DOWN keys to scroll through the Menus or press the ESC key to return to the normal operating mode
screen.
Note: Discharge and chilled water sensors are optional and must be installed to see screens.
22 • Mini dap4 User Manual
Analog Input
Chilled Water Sensor
Input B10
Offset xx.x
Value xx.x
