Data Aire Mini dap4 Installation, Operation & Maintenance Manual page 31

Set Point: The range is 70 to 90°F (factory setting is 80°F)
Note: If Hi Temp Alarm was set for NO – the Set Point will not appear on the screen
Press the ENTER key to advance to Lo Temp Alarm. The cursor will flash over the current setting. Press the UP or
DOWN key to change the setting.
Lo Temp Alarm: YES or NO (factory setting is YES)
Note: Choosing NO as the setting, the Low Temperature alarm will be disabled.
Press the ENTER key to advance to Set Point. The cursor will flash over the current setting. Press the UP or DOWN
key to change the setting.
Set Point: The range is 55 to 75°F (factory setting is 60°F)
Note: If Lo Temp Alarm was set for NO – the Set Point will not appear on the screen
Once a selection or selections have been made, move the cursor to the title block (Return Air Alarms) by pressing the
ENTER key
▼ Press the DOWN key to view the next screen:
The following will be displayed (values are for reference only):
Press the ENTER key to advance Hi Humidity Alarm. The cursor will flash over the current setting. Press the UP or
DOWN key to change the setting.
Hi Humidity Alarm:
Note: Choosing NO as the setting, the Hi Humidity alarm will be disabled.
Press the ENTER key to advance to Set Point. The cursor will flash over the current setting. Press the UP or DOWN
key to change the setting.
Set Point:
Note: If Hi Humidity Alarm was set for NO – the Set Point will not appear on the screen
Press the ENTER key to advance to Lo Humidity Alarm. The cursor will flash over the current setting. Press the UP
or DOWN key to change the setting.
Lo Humidity Alarm:
Note: Choosing NO as the setting, the Lo Humidity alarm will be disabled.
Press the ENTER key to advance to Set Point. The cursor will flash over the current setting. Press the UP or DOWN
key to change the setting.
31 • Mini dap4 User Manual
YES or NO (factory setting is YES)
The range is 35 to 90% RH (factory setting is 60% RH)
YES or NO (factory setting is YES)
Humidity Alarm
Hi Humidity Alarm: Yes
Set Point: 60%
Lo Humidity Alarm: Yes
Set Point: 40%
