3.5 MENU E – HISTORICAL DATA
MENU E allows viewing alarms, component runtimes and resetting of component runtimes
The first screen will display the most recent alarm (if any had occurred).
The following will be displayed (values are for reference only):
Time and Date of Alarm
Alarm Type
Humidity at time of occurrence
Chilled Water temperature at time of occurrence (if applicable)
Discharge Air Temperature at time of occurrence (if applicable)
To view consecutive alarms press the ENTER key moving the cursor into the -> field.
▼ Press the UP key and the display will show the previous alarm, with time and date. Continue to press the UP key
to view all alarms. Once the last listed alarm is viewed, press the ENTER to move the cursor back to the top of the
screen.
The screen will display the following:
▼ Press the ENTER key to move the cursor. The cursor will flash the reset choice of NO or YES. To reset and clear
runtimes, press the UP or DOWN key.
▼ Press the ENTER key until the cursor is flashing on the title line. Press the DOWN key to move to next screen.
▼ Press the ENTER key to move the cursor. The cursor will flash the reset choice of NO or YES. To reset and clear
runtimes, press the UP or DOWN key.
▼ Press the ENTER key until the cursor is flashing on the title line. Press the DOWN key to move to next screen.
17 • Mini dap4 User Manual
18:29:26 9/10/11
-> Scroll Up/Down?
Humidity High
Humidity: 59%
Return Air: 74.2 o F
Chilled Water: 0.0 o F
Run Hours 1 Reset
Blower: 0000 No
Comp 1: 0000 No
Comp 2: 0000 No
Reheat: 0000 No
Humidity: 0000 No
Dehum 0000 No
