Set the alpha time, and the adjustment range is 0~10S.
Slide the black scene switch to enable or disable the black function. Auto take on is the default state. If select
black scene and auto take on, the preview image will black or seamless switch to LED display instantaneously.
Click "Cut" or "Take", the preview will be cut or seamless switch to LED display.
EDID
Click the EDID shortcut " ", and pop-up window as follows:
The special display project or LED display application would like to require special resolution settings to meet
the requirement. Select the input or output board to read and write the EDID. As shown in the figure below:
Loop
Click the loop shortcut " ", and pop-up window as follows:
