RGBlink X2 Quick Start Manual page 19

Note
For example, set the top border, bottom border, left border and right border as 100, as shown in the figure
below:
Close monitor: Click the icon
shortcut on the right side of the interface to close all monitors.
Reset monitor: User can reset the monitor by clicking the shortcut
Swap monitor: User can swap the monitor by clicking the shortcut
shown in the figure below.
Auto tile: User can enable or disable the auto tile function by clicking the auto tile shortcut
side of the interface. If select auto tile "ON', the layer will automatically snap to the output grid when move the
layer to the position within the threshold value.
Monitor Size and Position Setting: Move the mouse to the lower right brink of the monitor, and press the left
key of the mouse. Move the mouse to the suitable position and release the mouse. But this method can only
adjust the size and location roughly, if an accurate adjustment is needed, select the monitor, and set the X, Y,
width and height in the bottom of the interface.
Monitor Size changed equivalently: Select any monitor, for example, select monitor 1, and adjust the size. Click
this monitor, then press button C and don't let go, select the monitor that will set, the size of the selected
monitor will be changed to the same size of monitor 1, as shown in the figure below:
Top border and bottom border, left border and right
border are changed equivalently. For example, if set
top border as 100, bottom border will be changed to
100 automatically, and if set left border as 200, right
border will be changed to 200 automatically.
on the top right corner of the monitor to close one monitor, or click the
18
on the right side of the interface.
on the right side of the interface, as
on the right
