VENUS X2
USER MANUAL
Article No: RGB-RD-UM-VENUS X2 E001
Revision No: V1.6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VENUS X2 and is the answer not in the manual?

Questions and answers

Related Manuals for RGBlink VENUS X2

Summary of Contents for RGBlink VENUS X2

  • Page 1 VENUS X2 USER MANUAL Article No: RGB-RD-UM-VENUS X2 E001 Revision No: V1.6...

  • Page 2: Table Of Contents

    5.1 Contact Us............................21 Chapter 6 Appendix............................22 6.1 Specification.............................22 6.2 Software Upgrade..........................28 6.3 Installing Options..........................29 6.3.1 Installing Input Module......................29 6.3.2 Installing WIFI Module......................32 6.3.3 Installing Power Module.......................34 6.4 Terms & Definitions......................... 37 6.5 Revision History..........................41 VENUS X2 User Manual...

  • Page 3: Declarations

    RGBlink. If the purchaser or a third party carries out modifications or repairs on goods delivered by RGBlink, or if the goods are handled incorrectly, in particular if the systems are commissioned operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid.

  • Page 4: Operators Safety Summary

    Installation Safety Summary Safety Precautions For all VENUS X2 processor installation procedures, please observe the following important safety and handling rules to avoid damage to yourself and the equipment. To protect users from electric shock, ensure that the chassis connects to earth via the ground wire provided in the AC power Cord.
  • Page 5 Site Preparation The environment in which you install your VENUS X2 should be clean, properly lit, free from static, and have adequate power, ventilation, and space for all components.

  • Page 6: Chapter 1 Your Product

    Chapter 1 Your Product 1.1 In the Box AC Power Cord Network Cable HDMI to DVI Cable Cable Serial DB9 to Screw Driver Antistatic Bag 3.5mm Jack Note: AC Power Cable supplied as standard according to destination market. VENUS X2 User Manual...

  • Page 7: Product Overview

    Chapter 1: Your Product 1.2 Product Overview VENUS X2 is a multiple outputs video processor, it offers nine card cages that accepts a wide variety of video signals, including VGA, CVBS, S-HDMI, SDI, HDMI, H.264, 4K and USB (for media files play).

  • Page 8: Back Panel

    The HDMI input can input the image signal from computer. The HDMI Loop can connect to the HDMI input of the next VENUS X2 or the device with HDMI input. Standard DisplayPort signals can be input for DP input. The DP Loop can connect to the DP input of the next VENUS X2 or the device with DP input.
  • Page 9 Connect to the U-LINK output of the next VENUS X2, adopt 3.5mm jack audio interface, for multiple cascade. U-LINK OUT Connect to the U-LINK input of the next VENUS X2, adopt 3.5mm jack audio interface, for multiple cascade. DIP Switch...

  • Page 10: Front Panel

    Push the button again will return to the last level menu or exit the menu. POWER Button Power button, push the button, the touch screen will pop up the confirm box, select “OK”, and turn the device off. Control Interface USB Interface Use for device upgrade. VENUS X2 User Manual...

  • Page 11: Dimension

    Chapter 1: Your Product 1.2.3 Dimension Following is the dimension of VENUS X2 for your reference: VENUS X2 User Manual...

  • Page 12: Chapter 2 Installing Your Product

    2.3 Turning on Your Product The device will enter to the boot interface, and OLED display will show as below, completing initialization before loading last settings and input/output configuration. On delivery, the output format is defaulted to 1920x1080x60. VENUS X2 User Manual...
  • Page 13 Chapter 2: Installing Your Product 维纳斯系列 VENUS SERIES X2 [>> VENUS X2 User Manual...

  • Page 14: Chapter 3 Using Your Product

    Push the [MENU] button to enter the menu display. Turn the rotary knob to navigate to the menu item required. The  symbol shows the current item. Push the knob to select and enter into the menu item. As shown in the figure below: VENUS X2 User Manual...

  • Page 15: Understanding The Menu Structure

    Chapter 3: Using Your Product 3.2 Understanding the MENU Structure The MENU structure is shown in the figure below: VENUS X2 User Manual...

  • Page 16: Using The Menu

    Chapter 3 : Using Your Product 3.3 Using the Menu Use the menu system for convenient and intuitive operation. VENUS X2 OLED display shows the menu items. The OLED display will show the default state when the menu is not in use, or the operation has timed out.

  • Page 17: Understanding The Main Menu

    RECALL SAVE PAGE 1 DELAY RECALL >> SCENE Save all current settings with the VENUS X2 to 1 of the 16 available slots. Restores/Loads all current settings with the VENUS X2 from 1 of the 16 RECALL SAVE available slots. SCENE Select the scene that will delay call.
  • Page 18 Set the alarm temperature. The device will alarm when reach the alarm TEMPERATUR temperature. UNIT Select the unit as ℃ or ℉. VENUS X2 provides 8 kinds of light style, user can select any mode from LIGHT STYLE mode 0 to mode 7 according to actual need. VENUS X2 User Manual...

  • Page 19: Language Menu

    3.3.6 Factory Reset Menu ->FACTORY RESET >> SAVE IP RESET >> FACTORY Select “YES” or “NO”. Select “YES” to restore default settings. RESET SAVE IP Select “YES” or “NO”. Select “YES” to restore default settings, but keep the RESET VENUS X2 User Manual...

  • Page 20: Chapter 4 Ordering Codes

    Chapter 4 Ordering Codes 4.1 Product 310-0002-01-0 VENUS X2 4.2 Options 4.2.1 Input Options 190-0002-02-1 Quad HDMI Input Module 4 × HDMI 190-0002-03-0 Triple VGA Input Module 3 × VGA 190-0002-04-1 Quad SDI Input Module 4 × SDI 190-0002-05-1 4 way CVBS Input Module 4 ×...

  • Page 21: Wifi, Comm And Power Module

    Chapter 4 : Ordering Codes 4.2.3 WIFI, Comm and Power Module 190-0001-12-0 Wi-Fi Module 190-0002-51-1 Comm. Module (X2) 950-0001-00-0 Hot Swap PSU 200W VENUS X2 User Manual...

  • Page 22: Chapter 5 Support

    Chapter 5 Support 5.1 Contact Us VENUS X2 User Manual...

  • Page 23: Chapter 6 Appendix

    VGA-UXGA (800×600@60 | 1024×768@60 | 1280×1024@60 | 1440×900@60 | 1600×1200@60 | 1920×1080@60) USB Input Module Interface Appearance Board Size 131.6(L)×20(W)（mm） Number of Inputs Connector USB-A Max Supported 1920×1080@60 Resolution Supported Standard Support general Image and video formats S-HDMI Input Module VENUS X2 User Manual...
  • Page 24 Number of Inputs Connector HDMI-A Supported Resolution VESA: 3840×2160@24 | 3840×2160@25 | 3840×2160@30 SMPTE: 625/25/50 PAL, 525/29.97/59.94 NTSC, 720p50/60 |1080i50/59.94/60 | 1080P50/59.94/60 Signal Level TMDS pwl, single pixel input,165MHz bandwidth Supported Standards HDMI 1.4 HDMI Loop VENUS X2 User Manual...
  • Page 25 640x480 | 704x576 | 720x404 | 720x480 | 720x540 | 720x576 | 850x480 |1024x576 | 1280x720 | 1680x1056 | 1920x1080 Refresh Rates 25~60Hz Supported Standards H.264/MPEG-4 AVC Decoding Protocols H.264 baseline/main/high profile L5.0 MPEG4 SP L0–3/ASP L0–5 MJPEG/JPEG baseline 3G-SDI Input Module VENUS X2 User Manual...
  • Page 26 SMPTE: 625/25 PAL, 525/29.97 NTSC, 625/50p PAL, 525/59.94p NTSC, 720p50/60 |1080i50/59.94/60 | 1080P50/59.94/60 VESA: 800×600@60 I 1024×768@60 I 1280×768@60 I 1280×1024@60 I 1600×1200@60 I 1920×1080@60 I 1920×1080@50 Supported Standards HDMI 1.3 SDI Output Module Interface Appearance Board Size 131.6(L)×20(W)（mm） Number of Outputs VENUS X2 User Manual...
  • Page 27 Supported Standards HDMI 1.3 WIFI Hotspot Module Certification FCC/CE Wireless Standard 802.11 b/g/n Frequency range 2.412GHz-2.484GHz 802.11b: +20dBm (Max.) 802.11g: +18dBm (Max.) Transmit Power 802.11n: +15dBm (Max.) Configurable 802.11b: -89dBm Receiver Sensitivity 802.11g: -81dBm 802.11n: -71dBm VENUS X2 User Manual...
  • Page 28 Function Switch Support any two inputs fade in fade out Extras Communication Windows control program, TCP/IP Power Supply 100-240V IEC-3 Working Environment 0°C~45°C Stored Environment 10% to 90% Product Warranty 3 years parts and labor warranty VENUS X2 User Manual...

  • Page 29: Software Upgrade

    Chapter 6: Appendix 6.2 Software Upgrade Upgrade the software by the USB interface in the front panel of VENUS X2, the upgrade steps are as follows: 1. Copy the “*.pkg” file to the USB disk, and modify the file name to “_update.pkg”.

  • Page 30: Installing Options

    VENUS X2 and VENUS X3 support replaceable input and output optional modules, user can install or replace the optional module according to actual need. The installation steps of VENUS X2 and VENUS X3 are the same. Here we take VENUS X3 for example, specific steps are as follows: Install the Optional Module 1.
  • Page 31 DVI input module: 3. Fix the input module block with fixed screws, as shown in figure: 4. Push the input modules into the device along the slide rail, and screw the captive screws, as shown in figure: VENUS X2 User Manual...
  • Page 32 Chapter 6: Appendix Note: The install steps of output module installation and input/output module replacement are the same as above. VENUS X2 User Manual...

  • Page 33: Installing Wifi Module

    2. Install the WIFI module as shown in the figure below: lock the WIFI module with 2 pieces of 2*5 flat head screws, then connect the antenna junctor and the connector with the WIFI antenna cable. VENUS X2 User Manual...
  • Page 34 2*5 flat head screw 3. Push the Comm modules into the device along the slide rail, and screw the captive screws, as shown in figure: 4. Install the external WIFI antenna, as shown in the figure below: VENUS X2 User Manual...

  • Page 35: Installing Power Module

    Chapter 6: Appendix 6.3.3 Installing Power Module One power module as standard for VENUS X2, as shown in figure 1: (Figure 1) If necessary, two power modules can be installed, the specific steps are as follows: 1. Unscrew the two M4 ground screws between the power module and power box with a...
  • Page 36 3. Push the power module into the slot, as shown in figure 4: (Figure 4) 4. Fix the two power modules with two M4 ground screws and a power module fixed holder, as shown in figure 5: VENUS X2 User Manual...
  • Page 37 Chapter 6: Appendix (Figure 5) 5. Fix the power box with two M3*8 flat head screws, and the installation is finished, as shown in figure 6: (Figure 6) VENUS X2 User Manual...

  • Page 38: Terms & Definitions

    Color burst is 3.58 MHz for NTSC and 4.43 MHz for PAL.  “Color temperature”: The color quality, expressed in degrees Kelvin(K), of a light source. The higher the color temperature, the bluer the light. The lower the temperature, the VENUS X2 User Manual...
  • Page 39 JPEG typically achieves 10:1 compression with little perceptible loss in image quality. Produces blocking artifacts.  “MPEG”: Motion Picture Expect Group. A standard committee under the auspices of the VENUS X2 User Manual...
  • Page 40 Low saturation is like adding white to the color. For example, a low-saturated red looks pink.  “Scaling”: A conversion of a video or computer graphic signal from a starting resolution to a new resolution. Scaling from one resolution to another is typically done to optimize the VENUS X2 User Manual...
  • Page 41 640×480 with a color palette of 16 bits and 256,000 colors.  “YCrCb”: Used to describe the color space for interlaced component video.  “YPbPr”: Used to describe the color space for progressive-scan (non-interlaced) component video. VENUS X2 User Manual...

  • Page 42: Revision History

    3. Add “Ordering Codes”. 4. Add 4K, H.264 and WIFI specification, etc. 5. Add “Installing WIFI Module”. 6. Add “Installing Power Module”. V1.6 2018-12-11 0006# 1. Update SDI output module Fanny 2. Update “In the Box” VENUS X2 User Manual...
