Service Manual
MP1

Technical specifications

MP1 design specifications

Features
Design
Direction of input rotation
Recommended installation position
Filtration configuration

MP1 technical data

Feature
3 3
Displacement (cm /rev [in /rev])
Flow at rated (continuous) speed (l/min [US gal/min])
Torque at maximum displacement (N•m/bar [lbf•in/1000psi])
Mass moment of inertia of rotating components (kg•m
Mass (kg [lb])
Oil volume (liter [US gal])
Mounting flange
Input shaft outer diameter, splines and tapered shafts
Auxiliary mounting flange with metric fasteners, shaft outer diameter
and splines
Main port configuration A, B
Case drain ports L1, L2
Suction ports S
Other ports
Customer interface threads
© Danfoss | April 2019
MP1
Axial piston pump with variable displacement using compact servo piston control.
Clockwise or counterclockwise
Pump installation position is discretionary, however the recommended control position is
on the top or at the side with the top position preferred. If the pump is installed with the
control at the bottom, flushing flow must be provided through port M14 located on the
EDC, FNR, NFPE, NFPH and MDC control. Vertical input shaft installation is acceptable. The
housing must always be filled with hydraulic fluid. Recommended mounting for a multiple
pump stack is to arrange the highest power flow towards the input source. Consult
Danfoss for non-conformance to these guidelines.
Suction or charge pressure filtration
28
28.0 [1.71]
95.3 [25.2]
0.45 [272.0]
2 2
[slug•ft ]) 0.0020 [0.0015]
29.6 [65.3]
1.5 [0.40]
ISO 3019-1 flange 101-2 (SAE B)
ISO 3019-1, outer Ø22mm - 4 (SAE B, 13 teeth)
ISO 3019-1, outer Ø25mm - 4 (SAE B-B, 15 teeth)
ISO 3019-1, outer Ø22mm - 1 (Straight
Key)
ISO 3019-1, flange 82-2, outer Ø16mm - 4 (SAE A, 9 teeth)
ISO 3019-1, flange 82-2, outer Ø19mm - 4 (SAE A, 11 teeth)
ISO 3019-1, flange 101-2, outer Ø22mm - 4 (SAE B, 13 teeth)
ISO 3019-1, flange 101-2, outer Ø25mm - 4 (SAE B-B, 15 teeth)
ISO 11926-1 - 1 1/16 - 12 (Inch O-ring
boss)
ISO 6149-1, M27x2 (Metric o-ring boss)
ISO 11926-1, 1 1/16 -12 (Inch O-ring boss)
ISO 6149-1, M27x2 (Metric O-ring boss)
ISO 11926-1 - 1 1/16-12 (Inch O-ring
boss)
ISO 6149-1 - M27x2 (Metric O-ring
boss)
ISO 11926-1, (Inch O-ring boss)
ISO 6149 -1, (Metric O-ring boss)
Metric fasteners
32 38
31.8 [1.94] 38.0 [2.32]
108.1 [28.5] 125.3 [33.1]
0.51 [308.9] 0.60 [369.1]
0.0030 [0.0022]
38 [83.8]
2.0 [0.53]
ISO 3019-1, outer Ø31mm - 4 (19 teeth)
ISO 3019-1, outer Ø25mm - 4 (Straight
Key)
ISO 3019-1, outer Ø25mm -3 (Conical
keyed, taper 1:8)
ISO 11926-1 - 1 5/16 - 12 (Inch O-ring
boss)
ISO 6162, Ø19mm, (Split flange boss,
M10x1.5)
ISO 6149-1 - M33x2 (Metric O-ring
boss)
ISO 11926-1 - 1 5/16-12 (Inch O-ring
boss)
ISO 6149-1 - M33x2 (Metric O-ring
boss)
AX00000244en-000201 | 9
45
45.1 [2.75]
149.5 [39.5]
0.72 [438.1]
