Product Overview
2 Product Overview
2.1 Enclosure Size Overview
Enclosure size depends on power range.
Enclosure size
J1
Enclosure
IP20
protection
High overload
rated power -
maximum
0.37–2.2 kW (380–480 V)
160%
1)
overload
Enclosure size
J5
Enclosure
IP20
protection
High overload
rated power -
maximum
18.5–22 kW (380–480 V)
160%
overload
1)
Table 2.1 Enclosure Sizes
1) Sizes 11–75 kW normal overload type: 110% overload 1 minute
Sizes 0.37–7.5 kW high overload type: 160% overload 1 minute
Sizes 11–22 kW high overload type: 150% overload 1 minute
Sizes 30–75 kW high overload type: 150% overload 1 minute
MG06B402
Design Guide
J2
IP20
3.0–5.5 kW (380–480 V)
J6
IP20
30–45 kW (380–480 V)
Danfoss A/S © 09/2014 All rights reserved.
J3
IP20
7.5 kW (380–480 V)
11–15 kW (380–480 V)
J7
IP20
55–75 kW (380–480 V)
2
2
J4
IP20
11
