Type Code and Selection

3.3.2 Ordering Numbers: Brake Resistors 40%

FC 360 P
m (HO)
T4 [kW]
HK37 0.37
HK55 0.55
HK75 0.75
H1K1 1.1
H1K5 1.5
H2K2 2.2
H3K0 3
H4K0 4
H5K5 5.5
H7K5 7.5
H11K 11
H15K 15
H18K 18.5
H22K 22
H30K 30
H37K 37
H45K 45
H55K 55
H75K 75
Table 3.3 FC 360 - Mains: 380–480 V (T4), 40% Duty Cycle
1) All cabling must comply with national and local regulations on cable cross-sections and ambient temperature.
MG06B402
Design Guide
R R R
min br. nom rec
[Ω] [Ω] [Ω]
890 1041.98 989
593 693.79 659
434 508.78 483
288 338.05 321
208 244.41 232
139 163.95 155
100 118.86 112
74 87.93 83
54 63.33 60
38 46.05 43
27 32.99 31
19 24.02 22
16 19.36 18
16 18.00 17
11 14.6 13
9 11.7 11
8 9.6 9
6 7.8 7
4 5.7 5
Danfoss A/S © 09/2014 All rights reserved.
P Code no. Period
br avg
[kW] 175Uxxxx [s]
0.127 3101 120
0.191 3308 120
0.260 3309 120
0.391 3310 120
0.541 3311 120
0.807 3312 120
1.113 3313 120
1.504 3314 120
2.088 3315 120
2.872 3316 120
4.226 3236 120
5.804 3237 120
7.201 3238 120
8.604 3203 120
11.5 3206 120
14.3 3210 120
17.5 3213 120
21.5 3216 120
29.6 3219 120
Cable Thermal Maximum
cross relay brake
torque
section 1)
with R
rec
[A] [%]
[mm 2 ]
1.5 0.4 139
1.5 0.5 131
1.5 0.7 129
1.5 1 132
1.5 1.4 145
1.5 2.1 131
1.5 2.7 131
1.5 3.7 128
1.5 5 127
1.5 7.1 132
2.5 11.5 130
2.5 14.7 129
4 19 132
4 23 128
10 32 150
10 38 150
16 47 150
25 61 150
35 81 150
