Bit 09, Selection of ramp 1/2
Bit 09=0: Ramp 1 is active (3-41 Ramp 1 Ramp Up Time to
3-42 Ramp 1 Ramp Down Time).
Bit 09=1: Ramp 2 (3-51 Ramp 2 Ramp Up Time to
3-52 Ramp 2 Ramp Down Time) is active.
Bit 10, Data not valid/Data valid
Tell the frequency converter whether to use or ignore the
control word.
Bit 10=0: The control word is ignored.
Bit 10=1: The control word is used. This function is relevant
because the telegram always contains the control word,
regardless of the telegram type. Turn off the control word
if not needed for it when updating or reading parameters.
Bit 11, Relay 01
Bit 11=0: Relay not activated.
Bit 11=1: Relay 01 activated provided that Control word bit
11=36 is selected in 5-40 Function Relay.
Bit 12, Relay 02
Bit 12=0: Relay 02 is not activated.
Bit 12=1: Relay 02 is activated provided that Control word
bit 12=37 is chosen in 5-40 Function Relay.
Bit 13, Selection of set-up
Use bit 13 to select from the 2 menu set-ups according to
Table 5.36.
Set-up
1
2
Table 5.36 Menu Set-ups
The function is only possible when Multi Set-Ups=9 is
selected in 0-10 Active Set-up.
Use 8-55 Set-up Select to define how bit 13 gates with the
corresponding function on the digital inputs.
Bit 15 Reverse
Bit 15=0: No reversing.
Bit 15=1: Reversing. In the default setting, reversing is set
to digital in 8-54 Reversing Select. Bit 15 causes reversing
only when serial communication, [2] Logic OR or [3] Logic
AND is selected.
MG06B402
Design Guide
5.11.2 Status Word According to FC Profile
Follower-master
Bit
no.:
Illustration 5.14 Status Word
Bit
00
01
02
03
04
05
06
07
08
09
10
11
12
Bit 13
0 13
14
1
15
Table 5.37 Status Word According to FC Profile
Explanation of the status bits
Bit 00, Control not ready/ready
Bit 00=0: The frequency converter trips.
Bit 00=1: The frequency converter controls are ready but
the power component does not necessarily receive any
power supply (in case of external 24 V supply to controls).
Bit 01, Drive ready
Bit 01=0: The frequency converter is not ready.
Bit 01=1: The frequency converter is ready for operation
but the coasting command is active via the digital inputs
or via serial communication.
Bit 02, Coasting stop
Bit 02=0: The frequency converter releases the motor.
Bit 02=1: The frequency converter starts the motor with a
start command.
Bit 03, No error/trip
Bit 03=0: The frequency converter is not in fault mode. Bit
03=1: The frequency converter trips. To re-establish
operation, press [Reset].
Danfoss A/S © 09/2014 All rights reserved.
(STW) (8-30 Protocol = FC profile)
STW Output freq.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Bit=0 Bit=1
Control not ready Control ready
Drive not ready Drive ready
Coasting Enable
No error Trip
No error Error (no trip)
Reserved -
No error Triplock
No warning Warning
Speed≠reference Speed=reference
Local operation Bus control
Out of frequency limit Frequency limit OK
No operation In operation
Drive OK Stopped, auto start
Voltage OK Voltage exceeded
Torque OK Torque exceeded
Timer OK Timer exceeded
5 5
75
