Danfoss VLT AutomationDrive FC 360 Design Manual page 71

RS485 Installation and Set-...
Coil 0
33 Control not ready
34 Frequency converter not ready
35 Coasting stop
36 No alarm
37 Not used
38 Not used
39 Not used
40 No warning
41 Not at reference
42 Hand mode
43 Out of frequency range
44 Stopped
45 Not used
46 No voltage warning
47 Not in current limit
48 No thermal warning
Table 5.17 Frequency Converter Status Word (FC Profile)
Bus Bus PLC
adress Register
register 1)
0 1 40001
1 2 40002
2 3 40003
3 4 40004
4 5 40005
5 6 40006
6 7 40007
7 8 40008
8 9 40009
9 10 40010
19 20 40020
29 30 40030
Table 5.18 Adress/Registers
1) Value written in Modbus RTU telegram must be one or less than register number. E.g. Read Modbus Register 1 by writing value 0 in telegram.
MG06B402
Design Guide
Content Access
Reserved
–
Reserved
–
Reserved
–
Free –
Free –
Modbus configu- Read/Write
ration
Last error code Read only
Last error Read only
register
Index pointer Read/Write
FC par. 0-01 Dependent on
parameter access
FC par. 0-02 Dependent on
parameter access
FC par. xx-xx Dependent on
parameter access
Danfoss A/S © 09/2014 All rights reserved.
1
Control ready
Frequency converter ready
Safety closed
Alarm
Not used
Not used
Not used
Warning
At reference
Auto mode
In frequency range
Running
Not used
Voltage warning
Current limit
Thermal warning
Description
Reserved for legacy frequency converters VLT 5000 and VLT
2800.
Reserved for legacy frequency converters VLT 5000 and VLT
2800.
Reserved for legacy frequency converters VLT 5000 and VLT
2800.
–
–
TCP only. Reserved for Modbus TCP (p12-28 and 12-29 -
stored in Eeprom etc.).
Error code recieved from parameter database, refer to WHAT
38295 for details.
Address of register with which last error occurred, refer to
WHAT 38296 for details.
Sub index of parameter to be accessed. Refer to WHAT
38297 for details.
Parameter 0-01 (Modbus Register=10 parameter number
20 bytes space reserved pr parameter in Modbus map.
Parameter 0-02
20 bytes space reserved pr parameter in Modbus map.
Parameter 0-03
20 bytes space reserved pr parameter in Modbus map.
5 5
