BACnet Network Objects

The following section contains relevant information needed
to integrate a MicroTech III WSHP into the BACnet network.
The data point differences between the Enfinity
Compressor, and the SmartSource
and Enfinity Large Two Compressor models are highlighted
below in the following tables:
• Table 1 - Table 7: Enfinity Single Stage Compressor
models MHC/MHW, CCH/CCW, VFC/VFW, LVC/LVW,
VHC/VHF (notes for all tables are shown at the end of
Table 7)
• Table 8 - Table 14: SmartSource Single and Two Stage
Compressor models GSH/GSV, GTH/GTV, GCV; Enfinity
Large Two Compressor models CCH/CCW, LVC/LVW
(notes for all tables are shown at the end of Table 14)
The Selected Parameters Information
Input Status and Binary Output Status

BACnet Data Points - Enfinity Single Stage Compressor

Models: MHC/MHW, CCH/CCW, VFC/VFW, LVC/LVW, VHC/VHF
Table 1: Analog Values - Enfinity Single Stage Compressor
Object Type/
Point Name
Instance
Local Space
AI:1
Temperature Output
Leaving Water
AI:2
Temperature
Entering Water
AI:3
Temperature
Discharge Air
AI:4
Temperature
Local Setpoint
AI:5
Adjust Output
Compressor
#1 Suction AI:6
Temperature
Compressor
#2 Suction AI:7
Temperature
Brownout Voltage
AI:8
Reading
www.DaikinApplied.com
Single Stage
™
Two Stage Compressor
®
section describes Binary
settings in greater detail.
Read/
BACnet Object
Write
Name
Access 2
ANALOG INPUTS
R LocalSpaceTemp
R LWT
R EWT
R DischAirTemp
R LocalSetpt
R SuctionTemp 1
R SuctionTemp
2
R Brownout
Please note that anytime a command is written to a configuration property,
this information is stored in the unit controller's non-volatile memory. Writing
to non-volatile memory is an operation that has a finite limit. For this reason,
the number of writes made to BACnet objects linked to configuration
properties must be limited to avoid damage to the hardware.
The BACnet Configuration and
Occupancy Modes, and
sections provide supplemental configuration and temperature
setpoint operation details. The BACnet PICS for each WSHP
model is included at the end of the document. See
A: Protocol Implementation Conformance Statements (PICS).
Refer to OM 1085 Software Downloading Procedures and
Troubleshooting Guide, available on www.DaikinApplied.com,
for software part number and compatibility details.
Non-
Range/Default
volatile
(in Units)
Memory 1
0 to 158ºF
The value of the hardwired space temperature sensor
-17.77 to 70ºC
installed either in the return air or the space. Writing to
N
Space Temp Input (AV18) does not affect Local Space
Default:
Temp (AI1) but does effect Effective Space Temp (AV22).
68ºF / 20ºC
0 to 158°F
-17.77 to 70°C
N Displays the leaving water temperature sensor value.
Default:
32ºF / 0ºC
0 to 158°F
-17.77 to 70°C
N Displays the entering water temperature sensor value.
Default:
32ºF / 0ºC
0 to 158°F
-17.77 to 70°C
N Displays the discharge air temperature sensor value.
Default:
32ºF / 0ºC
The reference setpoint used to determine the Effective
55 to 95ºF
Heating/Cooling setpoints. It is the value of the local,
12.78 to 35ºC
hardwired space temperature setpoint. It is only valid if
N
the unit controller JP5 configuration jumper is configured
Default:
for Long Range Setpoint Adjust and is enabled by
32ºF / 0ºC
MSV14.
0 to 158°F
-17.77 to 70°C
The compressor #1 suction line temperature sensor
N
value.
Default:
32ºF / 0ºC
0 to 158°F
-17.77 to 70°C
The compressor #2 suction line temperature sensor
N
value.
Default:
32ºF / 0ºC
The Brownout Voltage Reading is compared to the
0 to 1023 counts
N reference setpoint to determine if the brownout condition
Default: 0
exists.
5 ED 15103-6 • MICROTECH III WSHP UNIT CONTROLLER
C d
omprehensIve
CAUTION
Commissioning, Effective
Space Temperature Setpoint Methods
Description
See Effective Occupancy Modes.
6
6
6
T
aTa ables
C d T
omprehensIve aTa ables
Appendix
