Table 17: Network Configuration Properties Inputs (NCIs) - Enfinity Single Stage Compressor, Continued
l W
on orks
Point Name
(NV Index
HVAC Unit Type
nciHVACType
Identifier
Local Bypass Time
nciBypassTime
Setpoint
Location nciLocation
Minimum Send Time nciMinOutTm
Occupied Setpoint
nciOccDiff
Differential
1. Analog Null (0x7FFF) is a discrete temperature value of 621.806ºF/327.67ºC. Its purpose is to indicate a sensor failure condition or when the unit controller is not
using that temperature value.
2. The Network Variable (NV) index number is a unique identifier for certain L
reference these variables. The NV index number can also be found in the XIF file.
3. After Receive Heartbeat is enabled, this variable reverts to the default (non-override) value if it is not refreshed often enough through a network command or if
communication is disabled (i.e. the device is disabled or is offline).
ED 15103-6 • MICROTECH III WSHP UNIT CONTROLLER
Variable SNVT Type
2 ) (SNVT Index)
Network Configuration Property Inputs (NCIs)
SCPThvacType
SCPTbypassTime
SCPTlocation
SCPTminSendTime
UCPToccDiff
Range/
Heart-
Default
beat
(in Units)
Defines the primary application and equipment type for the
unit controller.
Do not modify this configuration property.
Supported Values
0 = HVT_GENERIC
0 to 9
1 = HVT_FAN_COIL
No
2 = HVT _VAV
Default: 3
3 = HVT_HEAT_PUMP (Default)
4 = HVT_ROOFTOP
5 = HVT_UNIT_VENT
6 = HVT_CHILL_CEIL
7 = HVT_RADIATOR
8 = HVT_AHU
9 = HVT_SELF_CONT
Defines the amount of time that the unit can be in the Bypass
mode initiated by the Timed Override button. Pressing the
0, 30 to 120 min
No Timed Override button 4-9 seconds sets the bypass timer to
Default: 120 min
the maximum nciBypassTime value. The value of 0 disables
this feature.
32 Characters No Provides descriptive physical location information for the unit.
Minimum period of time between automatic network variable
output transmissions. It limits network traffic when output
network variables are frequently changing. The value of 0
disables the timer.
Supported Variables
0 to 6553.4 sec
nvoBrownout
No
Default:0
• nvoDischAirTemp
(Disabled)
• nvoEWT
• nvoLocalSpaceTmp
• nvoLWT
• nvoSpaceTemp
• nvoSuctionTemp1
• nvoSuctionTemp2
Sets the Occupied and Standby Setpoint hysteresis to then
1 to 5°F
determine the Effective OFF setpoints.
0.55 to 2.78°C
No
Interaction Rules
Default:
• nciOccDiff < (occupied_cool – occupied_heat)
1ºF / 0.55ºC
• nciOccDiff < (standby_cool – standby_heat)
W variables. Some BAS companies use this numeric value instead of text to
on orks
32
C d T
omprehensIve aTa ables
Description
